V6 Deluxe Submersible Pump

V6 Deluxe Submersible Pump photo-1
Negotiable MOQ: 20 Units (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Gujarat, India
Brand Name:
Falcon
Model Number:
V6 Dlx Cut Model
Payment & Shipping
Payment Methods:
Port of Shipment:
Kandla Mundra. JNPT A'bad ICD
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Gujarat, India
Brand Name Falcon
Model Number V6 Dlx Cut Model
Theory Mixed Flow Pump
Structure Multistage Pump
Usage Water
Power Electric
Standard or Nonstandard Standard
Fuel Other, Electricity
Pressure Other
Application Submersible

Specifications

V6 Deluxe Cut Model Submersible Pump
Complete pumping solution
Cost effective
Zero maintenance
Durable submersible pump



6" Submersible Pumps


6” (150 mm) Submersible Pumps

FALCON 6” Submersible Borewell pump suitable for 6” borewell made with superior quality raw material, unique design to ensure best in-class performance with lowest operating cost and zero maintenance for years. Matchless and unique hydraulic design of bowl, impeller and diffuser put together construct the pump most energy efficient. Highly sophisticated engineering and State of the art manufacturing process results the world class quality, consistently.

Product Specification

  • Working condition for head range 80 feet to 1500 feet (Upto 450 Meters)
  • Flow range upto 80 M3/Hour

Salient Features

  • Hydraulic compact and high efficient design saves heavy electricity in compare to old conventional designed pumps
  • Stainless Steel AISI - 304 Grade Investment casting non magnetic pump bowls.
  • Stainless Steel AISI - 410 Grade pump impellers, available for mixed flow / radial flow
  • Stainless Steel AISI - 410 Sleeves are reinforced with chromium for proven wear resistance
  • Special LTB -4 and Nitrile Rubber Bush for proven anti-wear resistance
  • Pure Stainless Steel AISI 410 Grade Pump Shaft
  • Pump- Motor Coupling available as per ‘NEMA’ standard
  • Suction and NRV are of C.I. FG-220 / FG-250 Grade
  • Max. Sand quantity into the water: 50 g/m³.
