ac Capacitor With ul Approved

US$ 0.02 - 200 MOQ: 16 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

GHC

Model Number:

ac capacitor with ul approved

Dongguan City Gonghe Electronic Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name GHC

Model Number ac capacitor with ul approved

Type Aluminum Electrolytic Capacitor

Application AC / Motor

Package Type Through Hole

Capacitance 0.1uF~2,000,000uF

Rated Voltage 4V~630V

Operating Temperature -55℃~+135℃

ac capacitor with ul approved

others:

1.sell on credit accepted

2. with CE,UL,ROHS,ISO9000 certification

3. minimum order accepted

4.excellent after-sell service

widely used in UPS, inverter,electric car,microwave,motor start,elevator,air conditioner,

air compressor,washing machine,cosmetology equipment,main-board, power control system,

energy-saving lamps,digital camera,laser equipment and so on.

Items	Characteristics
Operating Temperature(°C)	-55~135°C
Rated Voltage Range (V.DC)	4~630VDC
Capacitance Tolerance	±20%(20°C, 120Hz)
Leakage Current	I less than 0.02CV OR 5mA (take the minimum)(apply rated voltage for 5 minutes)
Leakage Current	I: leakage current(A) C: rated capacitance V: rated voltage
Temperature Characteristics	Electrostatic Capacitance Range: c(-25°C)/C(+20°C) more than 0.7(120Hz)
Endurance	The following specification shall be satisfied when the rated voltage is applied for 2,000 hours at 85°C
	Capacitance change: ±20% of the initial value
	Dissipation factor(tan Ö): less than 200% of the initial specification value
	Leakage current: less than initial specification value
High-temperature storage	The following specifications shall be satisfied when the capacitor is stored for 500 hours at 85°C and be cooled down to 20°C and was handled according to the JIS C51024.4 term
	Capacitance change rate: ±20% of the initial testing value
	Dissipation factor(tan Ö): less than initial specification value
