Home > Manufacturing & Processing Machinery > Agricultural Machinery > Oil Presser > 2013 New Big Soybean Oil Expeller With Patent
2013 New Big Soybean Oil Expeller With Patent
US$ 1,800 - 2,300
MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Usage:
Soybean Oil
Type:
Other, Cold & Hot Pressing Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing Guangzhou Shanghai or any other China port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Big Soybean Oil Expeller With PatentUS$ 1,800 - 2,300MOQ: 1 Piece -
Advanced Big Sunflower Oil Press Machine With Water Cooling SystemUS$ 1,800 - 2,300MOQ: 1 Piece
-
Integrated High Quality Sesame Oil Press Citrus Oil PressUS$ 3,000 - 4,000MOQ: 1 Piece
-
Small Cooking Oil Extractor MachineUS$ 1,000 - 3,000MOQ: 1 Piece
-
Advanced Integrated Peanut Screw Oil Presser Food PresserUS$ 3,000 - 4,000MOQ: 1 Piece
Condition
New
Usage
Soybean Oil
Type
Other, Cold & Hot Pressing Machine
Automatic Grade
Automatic
Production Capacity
7.0 ton/24hours
Place of Origin
Sichuan, China
Brand Name
GUANGXIN
Model Number
YZYX120SL
Voltage
380V
Power(W)
11k.W
Dimension(L*W*H)
2150*1100*1350mm
Weight
808kgs
Certification
ISO, BV, CQC,CCC
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
2013 big soybean oil expeller with patent,-we obtain patent of it
-water cooling system keep nutrients of the oil
-factory
1. Guangxin Oil Expeller General Description
Adopting spiral squeezing structure and physical squeezing craft, the oil presser made by Guangxin is widely used in oil refinery and rural enterprises for squeezing oil from rapeseed, cottonseed, peanut, soybean, flax seed, tung oil seed, sunflower seed and palm kernel, etc. It has advantages of small investment, easy operating, high efficiency and strong compatibility, etc. Users could obtain good economic benefit from it. Main features are as below:
- Healthy! Physical squeezing craft maximally keeps the nutrients such as the protein, fatty acids and minerals, etc.
- High working efficiency! The spiral squeezing structure can achieve high oil output, the oil content of the residue cake is low. Oil plants only need to be squeezed by one time when using hot pressing.
- Long durability! Long durability: all the parts are made of the most suitable material and treated with refined crafts, such as cemented quenching and tempering to increase the hardness, consequently the durability.
- Cost-effective! The wearing parts on the machine such as the squeeze loop, squeeze spiral and squeeze bar are designed to be dismountable. When they are out of service period, users only need to replace them and no need to displace the whole machine.
2. YZYX120SL big soybean oil expeller with patent characteristics
- The YZYX12SL is one of our advanced screw oil presses with water cooling system and lengthened squeeze cage. Our company possess patent of it. The water cooling system makes sure the squeeze cage having constant proper temperature during working, so to avoid the nutrients, such as the vitamins, fatty acidsand manieral ets in the oil getting lost because of the rising temperature.
- The function of auto-warming up the press cage has replaced the traditional way by squeezing residue cake, It could shorten the preparation work and reduce the energy consumption. When the squeezing is suspended, the temperature can be maintained by this system.
- Longer press cage will generate stronger pressure, squeezing efficiency is high. The oil content in cake is only about 5.5%, much better than the national standard.
- Day capacity 7 ton/ 24hours.
3. YZYX120SL Suitable for
- Various oil plants, such as rapeseeds, cotton seeds, soybean, shelled peanut, flax seeds, sunflower seeds and palm kernel, etc.
- Oil sized oill refinery, oil mill and personal oil squeezing workshop.
- Performs well both in cold pressing and hot pressing.
4. YZYX120SL Technique Features
Technique Features | |
Product Name |
Spiral Oil Press |
Model |
YZYX120SL |
Processing Capacity (t/24h) |
7.0 |
Oil Conten of dry cakes (%) |
≤5.5 (best value) |
Power Required (KW) |
11 (Y160M-4) |
Measurement (mm) |
2150×1100×1350 |
Spiral axes rotate speed (r/min) |
37-45 |
Weight (KG) |
808 |
5. Quality Standard
- Conform to JB/T9793·1-1999 of the People's Republic of China & ISO9001:2008.
6. After-Sale Service
- We supply spare all year around.
- We supply technical solutions and helps for buyers at any time.
7. Certificate
8. Company display
We are your professional, reliable and cooperative parter & support in cooking oil press industry!
