Help CenterWSSP-411 RTD Bimetal Thermometer
Related Products
Technical Parameters
Technical parameters
Measuring range: -60 ~ 500 ℃
Display accuracy: 1.5
Remote signal deviation:
A. Graduation: E (nickel chromium-copper nickel) allowable deviation ± 2.5 ℃ or 0.75% t
B. Graduation: K (nickel chrome-nickel silicon) allowable deviation ± 2.5 ℃ or 0.75% t
C. Graduation: Pt100 platinum resistor () allowable deviation:
Class A: ± (0.15 + 0.002 t )
Class B: - (0.30 + 0.005 t )
D. Basic error with temperature transmitter: delta = delta 1 + / - 0.5% FS
delta 1 is thermocouple (resistance) basic error, FS is measuring range
Temperature transmission: two-wire system (4 ~ 20 mA), transmitter minimum working voltage is 12V, maximum 35 V, rated voltage 24V
Work environment:
A. environmental temperature: -25 ℃ ~ 80 ℃ (not higher than 70 ℃ in dangerous place)
B. relative humidity: 5% ~ 95%
C. mechanical vibration: f≤55Hz, amplitude < 0.15 mm
D. no corrosive medium in the environment
Environment temperature influence: ≤0.05%/1℃
Model
W |
S |
S |
Specifications |
|||||||
Temperature Instrument |
Metal expansion type |
bimetallic |
- |
|
|
|||||
|
4 |
|
Φ100mm |
|||||||
5 |
|
Φ150mm |
||||||||
Dial nominal diameter |
0 |
|
Angle or axial type |
|||||||
1 |
|
Straight or radial type |
||||||||
8 |
|
Universal type |
||||||||
structural style |
1 |
|
Movable male thread |
|||||||
2 |
|
Movable female thread |
||||||||
3 |
|
Movable Flange |
||||||||
Mounting type |
thermocouple |
|
|
|||||||
E |
|
nickel chrome- Copper nickel, type E |
||||||||
N |
|
Nickel chrome- nickel silicon, type K |
||||||||
Thermal resistance |
|
|
||||||||
Pt100 |
|
Platinum resistance |
||||||||
Cu50 |
|
Copper Resistance |
||||||||
|
|
|
|
|
|
|
Sensor |
|
Without temperature transmitter |
|
H2 |
The output and the temperature is in linear |
|||||||||
H4 |
Output and input signal is in linear |
|||||||||
temperature transmitter |
|
|||||||||
W |
S |
S |
- |
|
|
|
|
|
|
|
Note: customized based on requirements
WSS series bimetallic thermometer with thermocouple (resistance) and temperature transmitter is a temperature sensor for local display and remote signal transmission. It can indicate local temperature as well as transmit two-wire system signal of thermocouple (resistance) and temperature transmitter. As a new generation thermometer, it's widely used in metallurgy, petrochemical, electric power, textile, food, national defense and other industries. It's integrated type with thermocouple, thermal resistance and temperature transmitter, suitable for long-term working in harsh environment. Remote signal is of high accuracy and stability. It can also output two-wire signals directly, improve anti-interference performance during the process of long distance transmission. Favorable by users.
