QT6-15B Automatic Concrete Hollow Brick Machine Introduce
1.QT6-15B Automatic Concrete Hollow Brick Machine advantage
(1) This model automatic concrete hollow brick machine completely use PLC systems, human-computer interface and Chinese/English menu. It integrated with the advanced international mechanic, hydraulic and automatic technologies. Its easy for workers to communicate with the machine through color screen touch control system. The parameter is adjustable any time in accordance with the change of products and materials. it can analyze signal random, diagnosis fault and set parameter, this ensure the best work of the machine;
(2) About the electricity motor ,in Mixer and host machine ,we will use Germany siemens motor ,because this two part nearly working all time in working day ,so we could use high level hard wearing motor for this ,and ther motor we will also use CE standard motor ,
(3)About the switches ,we will select the France Schneider brand , it is could assure the working process smoothly .
(4) The Control System Using computer control and man-machine interface. Electrical equipments apply the well-known brands from Japan and Germany, like Japan Mitsubishi .
(5).The brick mould of brick making machine, in order to prolong the life of brick mould, we use the newest high temperature carburizing heat treatment technology, the quality is good.
(6).Hydraulic system :Hydraulic components made in Taiwan, we use high-dynamic proportional and directional valves, which automatically adjust the oil flux and pressure as per specific working requirements,
this design greatly prevent the cylinder from damage.
2.QT6-15B Concrete hollow brick machine main technical parameters
Dimension of host machine |
2850×2200×2850mm |
Moulding area |
800×600mm |
Moulding period |
15-20S |
The size of the pallet |
940×830×20/25mm |
Weight of the host machine |
6T |
Voltage |
380V |
Host machine power |
32KW |
Vibration force |
45KN |
Capacity |
91.55KVA |
Mixer model |
JS500 |
General water Consumption |
8T/every day |
3.Mixer: JS500 Mixer for QT6-15B
Main Technical Specifications |
parameters |
Feeding capacity |
800L |
Discharging volumn |
500L |
Productivity |
≥25m3/h |
|
Roating speed of stirring shaft |
2*8r/min |
Max.diameter of aggregates |
80/60mm |
Overall size |
3030×2300×2800mm |
Total mass |
4000kg |
Total capacity |
24.75KW |
Electric motor |
Siemens motors |
4.Production Capacity and block samples
Size(LxWxH):mm |
Pcs/Mould |
Pcs/ Hr |
Pcs/ 8 Hr |
|
230X110X70
|
30 |
5400-6300 |
43200-50400 |
|
400X100X200
|
12 |
2160-2880 |
17280-23040 |
|
400X150X200
|
8 |
1440-1920 |
11520-15360 |
|
400X200X200
|
6 |
1080-1440 |
8640-11520 |
|
400X250X200
|
4 |
720-960 |
5760-7680 |
|
Paver:200X100X60
|
24 |
3740 |
29920 |
|
Paver:200X163X60
|
9 |
1450 |
11600 |
Batching Machine
Automatic Stacker
Block sample
We will supply one year guarantee about our block making machine,when the client have the question ,they could call our service department number any time , we will supply per day 24 hours service .
Within one year ,if the client meet the unsolvable questions ,we could fly to client place to help.
Sincerely hope we can cooperate with each other.
