Home > Electrical & Electronics > Antenna > Communication Antenna > 200W N-M RF Terminations

200W N-M RF Terminations

Name: 200W N-M RF Terminations
Brand: SETSAIL
SKU: 132979761

Negotiable MOQ: 20 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Anhui, China

Brand Name:

SETSAIL

Model Number:

YFTX-RFT-200-3G-NC

Contact Supplier Request Quote Chat Now

Hefei Setsail Telecom Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Anhui, China

Brand Name SETSAIL

Model Number YFTX-RFT-200-3G-NC

Specifications

1. Manufacturer of RF terminations
2.capable of bearing high-power impact
3. OEM services
3. Two years warranty

Product Name: 200 watts, N-male/female, DC-3G, Terminations,Dummy Load,Termination Load

Mechanical Specifications
Model Number	YFTX-RFT-200-3G-NC
Frequency(GHz)	DC-3G
VSWR(max)	1.15
Connector	Brass Nickel Plated
Male Pin	Brass Silver Plated
Female Pin	Brass Silver Plated
Temp Range	-55°C~+125°C
Dimensions	200mm142mm64mm

Nominal Impedance: 50ohm

Average Power:200W

Peak Power: 1KW (5us pulse width with 2.5% duty cycle)

Connector Type: N-male or N-female or DIN-male or DIN-female

Notes:

1. Dimensions Tolerance: ±0.2

2.Dimensions and specifications refer to connector type N unless otherwise specified.

3. Custom designs available.

We are capable of manufacturing and providing 1W, 2W, 5W, 10W, 15W, 20W, 25W, 30W, 50W, 100W, 200W, 300W, 500W RF Dummy Load. The Frequency can reach DC-3G, DC-6G, DC-8G, DC-12.4G ,DC-18G, DC-26G, DC-40G. RF Connectors can be N-type, SMA-type, DIN-type, TNC-type and BNC-type.
