Ceramic Fiber Paper( High Quality RCF Paper)

Ceramic Fiber Paper( High Quality RCF Paper) thumbnail-1
Ceramic Fiber Paper( High Quality RCF Paper) photo-1
US$ 5,340 - 5,500 MOQ: 1 Ton
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Application:
Refractory
Thickness:
1-6mm
Contact Supplier Request Quote Chat Now
Shandong Luyang Energy-Saving Materials Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Application Refractory
Thickness 1-6mm
Width 610-1220mm
Length 10-50meter
Grade ST (Standard)
Chemical Composition aluminia silica
Working Temperature 1100/1200
Fiber Diameter 3.5
Brand Name LUYANGWOOL
Model Number 1260rz

Specifications

Ceramic wool paper
Density: 200-250kg/m3
Thickness: 1~6mm
Temperature:1260C
Customized service is also available.

  • LUYANGWOOL® ceramic wool paper is a lightweight refractory material processed from a blend of high purity alumina-silica fibres into a highly flexible, uniform sheet. It is recommended for classfication temperatures up to 1260C. Ceramic fiber paper has low shirngkage, good handling strength, and low thermal conductivity. It contains a small amount of orgainc binder for processing which makes it flexible, and reduces off-gassing and odour during use. Our product has a highly uniform structure due to its controlled basis weight and thickness, assuring homogeneous thermal conductivity and a clean, smooth surface ideas for gasket or sealing. Ceramic fiber paper is completely free of asbestos, and is designed to be an economic replacement for asbestos paper in most applications. Ceramic fibre paper is easy to cut with a knife, shears, or standard steel rule dies. Its flexibility allows it to be wrapped or rolled to fit most complex configurations.

           Application

  • Abestos paper replacement
  • Investment cast mold wrap insulation.
  • One-time consumable insulating applications
  • Back-up lining for metal troughs.
  • Hot top linining
  • Applications where low binder content is required.
  • Thermal and electrical insulation
  • Upgrade for fiber glass paper and blanlet products



  Technical Data Sheet

Description

STD PAPER

HP PAPER

Chemical Composition (%)





Al2O3

47

48

SiO2

52

51

Fe2O3

≤0.5

≤0.5

Na2O

≤0.2

≤0.2

Physical Properties





Density(kg/m3)

        200

   250

Classification Temperature ( °C )

1260

1260

Maximum Operating Temperature( °C )

1000

1100

Organics Content (%)





Color

white

Loss of Ignition ( % )

≤10

Tensile Strength(Mpa)

≥0.3



          Technical Data Sheet

  • Moisture content (%)  ≤ 1
  • Organic content : ≤10%
  • Tensile strength (Mpa) ≥ 0.3

          Standard Specification

  • Width:  610/1220mm
  • Thickness: 1/2/3/4/5/6mm
  • Density: 200-250kg/m3

      Customized service is also available. For more information,please contact us !
