Specifications
Ceramic Fiber PaperDensity: 200-250kg/m3
Thickness: 1~6mm
Temperature:1260-1350C
Customized service is also available.
LUYANGWOOL® ceramic fiber paper is a lightweight refractory material processed from a blend of high purity alumina-silica fibres into a highly flexible, uniform sheet. It is recommended for classfication temperatures up to 1260C. Ceramic fiber paper has low shirngkage, good handling strength, and low thermal conductivity. It contains a small amount of orgainc binder for processing which makes it flexible, and reduces off-gassing and odour during use. Our product has a highly uniform structure due to its controlled basis weight and thickness, assuring homogeneous thermal conductivity and a clean, smooth surface ideas for gasket or sealing. Ceramic fiber paper is completely free of asbestos, and is designed to be an economic replacement for asbestos paper in most applications. Ceramic fibre paper is easy to cut with a knife, shears, or standard steel rule dies. Its flexibility allows it to be wrapped or rolled to fit most complex configurations.
Technical Data Sheet
Description |
STD Paper |
HT Paper |
Chemical Composition (%) |
|
|
Al2O3 |
47 |
48 |
SiO2 |
52 |
51 |
Fe2O3 |
≤0.5 |
≤0.5 |
Na2O3 |
≤0.2 |
≤0.2 |
Physical Properties |
|
|
Density (kg/m3) |
200 |
250 |
Classification Temperature ( 0C ) |
1260 |
1430 |
Maximum operating temperature ( 0C ) |
1100 |
1200 |
Organic matter content (%) |
≤9 |
|
Color |
White |
|
Loss Of Ignition(%) |
≤10 |
|
Tensile Strength (Kpa) |
≥0.3 |
|
Standard Specification
- Width: 610/1220mm
- Thickness: 1/2/3/4/5/6mm
- Density: 200-250kg/m3
Customized service is also available. For more information,please contact us !
