JL Small Type Switch Oil Refueling & Filtering Machine
Usage:
This machine is fit for oil-using departments and corollary equipments. It can be used in the filtration of mechanical impurity, high-lift and long-distance oil pumping and injection.
Characteristics:
---This type of machine filters by three steps whose filtering elements gradually become intensive. It doesn’t need filter paper with several advantages such as: portable,easy-handling and environment protection .etc. It can not only filter the impurities in oil, but also satisfy the high-lift and long-distance oil pumping and injection.
Technical Parameters
Model |
JL-30 |
JL-50 |
JL-70 |
JL-100 |
JL-150 |
JL-200 |
JL-250 |
JL-300 |
|
Flow (L/min) |
30 |
50 |
70 |
100 |
150 |
200 |
250 |
300 |
|
Lift |
5m |
8m |
8m |
10m |
12m |
15m |
15m |
15m |
|
Filter precision |
5µm |
5µm |
5µm |
5µm |
5µm |
5µm |
5µm |
5µm |
|
|
Total Power (kw) |
0.55 |
0.75 |
1.1 |
2.2 |
3 |
3 |
4 |
4 |
|
Power |
50HZ 380V |
||||||||
inlet (outlet) diameter |
Made according to the customers’ demand |
||||||||
mm Dimension |
L |
560 |
650 |
650 |
700 |
700 |
800 |
800 |
800 |
W |
450 |
500 |
500 |
550 |
550 |
580 |
580 |
580 |
|
H |
450 |
500 |
500 |
550 |
550 |
580 |
580 |
580 |
|
Attention: Dimension and weight will be changed with changing the technical specification.
