CE SGS TUV Long Throw Distantce DS-200 dust control fog cannon For demolition explosion construction
Certification
Product advantage & Feature
1. Professional manufacturer with over 20 years' experience, high quality, best service and competitive price, offer multiple choices of product to meet different requirements.
2.Strong capability, high & far throw range, wide coverage area, achieve precise volume spraying, high efficiency and spray speed.
3. Micro fog droplet, form a wet mist touching the floating dust, high speed knock down the dust.
4. Flexible power: three-phase 380V and diesel generator power supply optional
5. Flexible installation, fixed on the concrete platform or diesel generator-powered vehicles optional.
6. Flexible, safe & reliable to use. Remove control & manual control operation. Easily adjust the spray angle of horizontal rotation.
7. Compare to tank car, water consumption save 70% ~80%, wide coverage area.
Scope of Application
We offer a wide range of different equipment which can be used for dust suppression in various ways on a multitude of different building sites. such as Mine, Coal yard, Ports,Docks, Steel mill, Raw Material Crushers,Truck Dumping Points, and other large construction site, etc.
Epidemic Prevention in large area such as City streets, Stations, Ports, Public Places, Landfills, etc.
Also apply to urban landscaping, farmland & forest, greening of roads, grassland, pasture, pesticide spraying and pest control, etc.
Technical parameters
| Model | DS-200 |
| Throw | 200m |
| Volume Flow (Adjustable) | 120~240L/min |
| Fog Droplet Size (Adjustable) | 30-300um |
| Water Pressure (Mpa) | 2.5~3.5Mpa |
| Horizontal Rotation Angle | ±160° Automatic |
| Pitching Angle | -10°~45° |
| Overall Dimensions (L*W*H) |
L4300*W1750*H3200 (mm) |
| Net Weight | 4140 kg |
Working Principle
When droplets are produced equal to that of dust particles, the airborne dust is suppressed through particle agglomeration! And DS-200 sprayer's fog droplet size is 30~300um, It is small so that the dust particle can more easily impacts the droplet!
Working View
