Help CenterFreon Gas Filling Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Commodity
Packaging Type:
Cans
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Under Cap Aerosol Filling Machine for FreonNegotiableMOQ: 1 Set -
Refrigerant Gas Filling MachineNegotiableMOQ: 1 Set
-
Under Cap Aerosol Filling MachineNegotiableMOQ: 1 Set
-
Under Cap Filling Machine for FreonNegotiableMOQ: 1 Set
-
Under Cap Aerosol Filling Machine for R134a With 1000gNegotiableMOQ: 1 Set
Condition
New
Application
Commodity
Packaging Type
Cans
Packaging Material
Wood
Automatic Grade
Semi-Automatic
Driven Type
Pneumatic
Place of Origin
Jiangsu, China
Brand Name
MEITAR
Model Number
QGBG1000
Certification
ISO9001:2000
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Freon gas filling machineproduction capacity:800-1200canS/hour
Filling volume: 1000g(Max)
filling tolerance:+-1%
Freon gas filling machine (Cold Media Machine) is applicable for the production of aerosol product which is injected into the aerosol can that uses core-free valve at first, and then the can is capped at the same step. The machine with high security, easy adjustment and operation, precise filling metering, high capping speed, and sound tightness etc.
Part II: Specification
Type |
QGBG1000 |
|
Capping Dia. (mm) |
26.5-28.5 |
|
Capping Depth (mm) |
0-7 |
|
filling Capacity (g) |
Max.1000g (optional) |
|
filling Precision |
under±1% |
|
Vacuum Degree (MPa) |
-9.3×10-2 |
|
Air Valve Applied |
1 inch (25.4mm) |
|
Aerosol Can Applied |
Height (mm) |
60-350 |
Dia. (mm) |
32-85 |
|
Operation Pressure (MPa) |
0.5-0.7 |
|
Max. Air Consumption (L/min) |
14 |
|
Production Capacity (Can/hr.) |
350-700 |
|
Sizes (mm) |
900×550×1620 |
|
Weight (kg) |
135 |
|
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2007
Factory Size
10,000-30,000 square meters
Total Employees
51 - 100 People
