2d barcode marking machine is one of the fast moving marking machine.
As a factory,we will give you the highest quality and the competitive price.
We are looking for the agent for marking machine all over the world.
Introduction of marking machine :
XINTIAN-series fiber laser marking machine is a new generation laser marking system made with newest laser technique in the world , It design with fiber laser maker as laser source, and thru high-speed vibration-mirror scan system to actualize marking function, the fiber laser making machine have high conversion efficiency of electric-light, It use air-cooling systems,the size of whole machine is compactness,the laser beam quality is excellent. this machine is widely applied to marking metal and some metalloid materials,mainly used to the field which request high quality to deepness, smoothness and precision, such as horologe,communication products images marking etc.
Features of mini laser marking machine :
1.Germany IPG brand fiber laser.
---Long lifetime,over 100,000 hours.
---Compact laser source with air cooling.
---2 to 5 times more productive a traditional marker.
2.Super quality Germany Scanlab brand galvanometer scanning system.
---High accuracy and repeatability for correct marks each time with galvanometer scanners and electronic controls.
----More stable performance.
3.Output power is stable,optical mode is good,beam quality is excellent.
4.Marking speed is fast,efficient,and high accuracy.
5.Appearance is professional,operation is simple.
6.Two model choices:desktop or free-standing.
7.Runs without maintenance,without consumables,great for continuous working.
8.CE certificate.
9.The software controlling system has the interface of Windows and comprises files output by software such as CORELDRAW, AUTOCAD, PHOTOSHOP, etc. It can support graphic file formats such as PLT, DXF, PCX or BMP etc. And use fonts such as SHX, TTF directly. It also can mark automatic code, sequence number, batch number, date, bar code and two-dimensional code. The software can mark the figures on the opposite side.
Highlights of fiber laser marking machine:
• High Marking Speed
• Perfect beam quality
• Very Compact
• Low Consumption
• Maintenance Free and long working life
Advantages:
- Fiber lasers are up to ten times more efficient than traditional YAG or CO2 laser systems. Consuming little to no energy when not active, the annual energy saving can attract government grant funded energy efficiency programs for industry.
- Fiber lasers have no optic to adjust or align, and no lamp to replace. Maintenance is minimal and so utilization and up-times are maximized. The lasers really are designed as shop floor industrial tools.
- Applicable materials and industries:
- Suitable for all kinds of metals, industrial plastic, electroplates, metal-coated materials, rubbers, ceramic, and so on.
- Widely used in fields like mobile button, plastic transparent button; electronic arts, IC, tools, communication products; bathing products, tool accessories, glasses and watches, jewelry, button decoration for boxes and bags, cookers, stainless steel products and so on
Technical Parameters:
Laser power |
10W/20W |
Min. characters |
0.15mm |
Laser Wavelengths |
1064nm |
Orientation precision |
0.002mm |
Beam quality |
M2<2 |
Average power consumption |
500W |
Laser Repetition Rate |
20-100KHZ |
Power |
AC220V±10%/50Hz/5A |
Marking speed |
≤8000mm/s |
Cooling style |
Air cooling |
Min.width |
0.01mm |
Laser tube lifetime |
100000Hours |
Working area |
70mmX70mm |
Dimension
|
680X200X450mm
|
100mmX100mm | |||
160mmX160mm |
G.W |
32Kg |
Machine picturs:
Sample Pictrues:
Workshop:
About packaging term:wooden box:
We attend lots of exhibition:
My name card:
