coding and marking machine is one of our company fast moving marking machines.
PRODUCT DETAILS
coding and marking machine are detailed as follow:
Good quality! Lowest price!! Best service!!!
Introduction:
With high speed scanning resonance mirror to get high precision and high speed Thesoftware controlling system has the interface of Windows and comprises files output by software such as CorelDraw, AutoCAD, and Photoshop It can support graphic file formats such as PLT, PCX, DXF, and BMP; and use fonts such as SHX and TTF directly It also can mark automatic code, sequence number, batch number, date, bar code and two-dimensional code. The software can mark the figures on the opposite side You can use the computer to design figures and characters randomly, so it's very flexible and convenient. It won't waste printing materials so the processing cost is low Laser marking is non-toxic, wear and without deformation or pollution You can choose revolving worktable which is suitable for marking round products
Product application:
It can be used in the industries of metal, alloy and oxide, ABS, epoxy resin, printing and ink. It's widely used in the industries such as electron component, electric appliance, jewel, glasses.
Remarks:
A set of machine is composed of the path of rays, cold water tank, control chest, monitor, worktable and outside-set air conditioner. You can choose revolving worktable and automatic matching system.
Technical parameters:
Machine Model |
Laser Marking Machine |
Type specification |
YAG |
Wave length of laser |
1.064μm |
Acousto-optics modulation frequency |
200Hz~50kHz |
Laser power |
≤50W |
The max. marking speed |
7000mm/s |
The marking scope |
110*110mm(Optional) |
Repetition precision |
0.01mm |
The marking depth |
0.05mm~0.2mm (according to the material) |
Power supply |
380V (220V) / 50Hz / 5kVA |
Cooling way |
Integration constant temperature circulation water cooling |
N.W |
400 |
G.W |
480 |
Packing Size |
1.75*0.75*1.2m |
Delivery Date |
5 working days |
Marking photos
COMPANY PROFILE
Jinan Xintian Technology Co.,Ltd is professional manufacturer of laser equipment, established in 2004.
It is a professional manufacturer engaged in the research,development, production and service of
Diode pumped Laser marking machine, Fiber laser marking machine,CO2 laser marking machine,Pneumatic marking machine,Laser engraving machine,Laser welding machine, Laser cutting machine and Laser trimming machine.
CERTIFICATE
coding and marking machine has passed the CE certificate and ISO9001:2008.
NAMECARD
OTHER PRODUCTS:
Except coding and marking machine we have other models for your check:
Fiber laser marking machine,pneumatic marking machine,CO2 RF laser marking machine
