YAG Laser Marking machine
Features:
1:German High-speed marking galvo head,high photoelectric conversion efficiency,high markingspeed,fine and permanent marking results .
2:Full optical seal technology,low fault rate,maintence free.
3:It is able to work with diode side pump,diode end pump,fiber and many other types of laser sources.
4:Automatic focus detective and adjustment system can be equipped to meet the drivers needs of marking.
Applicable fields:
Suitable for all kinds of ordinary metals and alloys(Iron,copper,aluminium,magnesium,zinc and all metals);rare metals and alloys (gold,silver,titanium);metal oxides,ABS material (electrical appliances case,daily necessities),ink (translucent key-press,printing products),epoxy resin(electronic components packaging,insulation layer).
Technical parameters:
Laser beam quality |
≤6 |
Max.Outout Power |
≤75W |
Laser Wavelength |
1064nm |
Repetition Frequency |
≤50KHZ |
Standard Marking Scope |
150mmX150mm(optical) |
Marking Depth |
≤0.50mm |
Marking speed |
≤7000mm/s |
Min.Line Width |
0.015mm |
Min.Character |
0.4mm |
Repetition Precision |
±0.01mm |
Machine power |
1.5KW |
Electric Power Demand |
220V/Single Phase/50Hz/8A |
Optical-Path System Size |
1220mm*650mm*1200mm |
Controlling Size |
600mm*600mm*800mm |
Cooling System |
1.6kwChiller(Different configuration on different laser sources) |
Galvo postioning precision |
0.005mm |
Samples:
