2014 laser engraving aluminum + Skype:xtlaser_xu
Welcome to contact Xintian by leaving a message below or send inquiry to lasermachine02(at) for further information.Your kind response of below questions will help us to recomemnd the most suitable model to you asap.
1,Are you looking for laser cutting machine or laser engraving machine?
2,Which material need to cut or engrave ?
3,What is the thickness and size of materials?
laser engraving aluminum + Skype:xtlaser_xu
High Speed Laser Engraving Machine&Laser Cutting Machine adopts the new high-efficiency laser tube, the laser beam is more stable than the traditional type,and the life time of the laser tube is very long.
more scientific design and high-strength steel-frame structure , which increase the fuselage strength more than 40% to prevent the machine from distortion during long term work.
The humanized and modern appearance shows Ruofen’s consistent humanity idea, and it also makes the operation and maintenance quite easy.
Advanced DSP control system, professional motion control chip, consecutive high speed curve cutting and the shortest path selection function improve the working efficiency a lot.
Application Materials
Laser engraving machine can both cutting and engraving many materials
| Material | Cut | Engrave |
| Acrylic, Plexiglass, Pmma, Perspex, Organic board, Double color plate | Yes | Yes |
| Plastic, PP, PET, PC, PMMA, PS, PES, PA, Plastic Foils&Films, Polycarbonate, polyester or polyimide membrane keyboards | Yes | Yes |
| Wood, Bamboo, Veneer, MDF, Blasa wood, Plywood | Yes | Yes |
| Leather, Pig leather, Cow Leather, Sheep leather | Yes | Yes |
| Textile, cotton, silk, felt, lace, synthetic & technical textiles, aramid, polyester, fleece | Yes | Yes |
| Foam & Filter, Mats Polyester (PES), Polyethylene (PE), Polyurethane (PUR) Neopren® |
Yes | Yes |
| Paper, Cardboard, Chipboard, Press Board | Yes | Yes |
| Stone, Ceramic, Granite, Marble, Natural stone, Pebble stone, Slate | No | Yes |
| Rubber stamps, Synthetic & Silicone Rubber, Natural rubber, Microporous foam Silicone rubber, Synthetic rubber |
Yes | Yes |
| Glass, Pressed glass, Float glass, Crystal glass, Mirror glass | No | Yes |
laser engraving aluminum + Skype:xtlaser_xu
Demo sample of CO2 laser engraving machine,laser cutting machine
MDF laser cutting sample
Wood laser cutting sample
Plywood laser cutting sample
laser engraving aluminum + Skype:xtlaser_xu
Feature of Co2 laser engraving machine,laser cutting machine
1. CO2 Glass sealed laser tube
(Chinafamous brand,Good beam mode stability,service time over 6000~10000 hours
2. Laser Power
good quality and stable power output to extend the laser tube service time.
3. Imported II-VI ZnSe focus lens( High transmittance,good focusing effect and stability 4.DSP control system
USB interface,support online/offline work,English language system,Adjustable cutting speed and power
5.Japan Stepper motor drive and belt transmission
6.Linear guide rails:Taiwanese made famous
7.Industrial Cooling System
the constant water temperature,ensure laser tube a longer service time and high stability
8.Exhaust Fan: exhaust dust and smoke device
9.Electical Magic Air compressor: the huff protection,protect the laser head focus lens clean
10.Emergency Stop
11. Honeycomb or Slatted worktable optional
Honeycomb worktable for cutting fabric leather etc soft material
Aluminum knife worktable for cutting acrylic etc hard material
12. Routeway feeding:allow users of roll material with unlimited length
13.Optional up & down adjustable worktable:Can engrave & cut different height materials
14.The alarm device optional
15.Portable laser cutting machine: with wheels , easy to move and fixed
laser engraving aluminum + Skype:xtlaser_xu
Laser Cutting Machine Technical Specifications | ||
Model |
XTE-1290 |
|
Cutting area |
1200x900mm |
|
Laser power |
80w |
|
Laser type |
CO2 sealed laser tube,water-cooled,10.6um |
|
Cutting speed |
0-50000mm/min |
|
Laser Output |
1-100%software setting |
|
Resetting positioning accuracy |
±0.01mm |
|
Power supply |
AC 110 - 220V ± 10%, 50 - 60Hz |
|
Operating temperature |
0 - 45°C |
|
Operating humidity |
5 - 95% |
|
Min. shaping character |
English 1.0mm x 1.0mm |
|
Graphic format supported |
BMP, PLT, DST, DXF, AI |
|
Software supported |
Tajima,CorelDraw, PhotoShop, AutoCAD |
|
Driving system |
Stepper |
|
Cooling mode |
Water-cooling and protection system |
|
Equipment Dimensions |
1.72*1.31*1.07m |
|
Net Weight: |
350kg |
|
Optional Spare Parts |
Up-down clump, Rotary System, Red Light Pointer |
|
Recommended Spare Parts |
Laser Tube and Lens |
|
laser engraving aluminum + Skype:xtlaser_xu
Parts of Co2 laser engraving machine,laser cutting machine
laser engraving aluminum + Skype:xtlaser_xu
Package of Co2 laser cutting machine,laser engraving machine
$Keywords$
laser engraving aluminum + Skype:xtlaser_xu
Guarantee & After sales Service
Laser tube guaranteed 10 months. While the whole machine guaranteed for 1 year.
24 hours technical support by email or calling
user-friendly English manual and operation video CD
laser engraving aluminum + Skype:xtlaser_xu
Our Certifications of CO2 laser engraving machine,laser cutting machine
How to Contact Us? Co2 laser engraving machine,laser cutting machie
How to order Co2 laser engraving machine,laser cutting machine from us
laser engraving aluminum + Skype:xtlaser_xu
How to choose a laser machine?
1)Machine quality.If you plan to choose a so cheap machine,maybe the quality is bad.And you have to order another machine after you use it for a period.This situation will have a bad effect on your producing.So the quality of the machine is most important factors to choose a laser machine.
2)Future more,after-sales service is very important, too.Good after-sales service represent the image of a company .After you use the machine and find some problem of machine, a good after-sales can solve it effectively and protect the rights of consumers.
3)The third is technical support.Because of time difference,there is a big problem to communicate with the seller. When you need help, maybe it is the sleeping time for the sellers. So the effectively contact information and serve is also useful to you. Other sellers maybe can not do this, but our company can provide 24th service a day.
4)The last is company. In order to ensure their image, a company with good reputation usually can produce good quality machine .As our company, we specialized in CNC laser machine is more than 8 years, the professional engineer teams,the advanced equipment and the good service have earned us good reputation in world market.
Contact us
Welcome to contact us,we will do our best for you.
CO2 Laser Cutting machine prices good and distributors wanted!!!
We will be very happy to help you in any way we can.
E-M-A-I-L: lasermachine02(at)
Skype:xtlaser_xu
WEB: /
laser engraving aluminum + Skype:xtlaser_xu
...
