Street Light Solar Charger Controller for lighting PETC-K02
Technical parameters
Items |
Solar Charge Controller
|
Rated Charge Current |
20A,12V/24V Auto |
Rated Load Power |
Rated Voltage:12V:≤100W Rated Voltage:24V:≤200W Note: Depend on the power of LEDs |
System Voltage |
12V/24V Auto |
No-load Consumption |
≤6mA |
Recharge circuit reduction voltage |
≤0.26V |
Discharge circuit reduction voltage |
≤0.15V |
Temperature compensation |
-5mv/°C/2V |
Working temperature |
-35°C~55°C |
Control Type |
PWM |
Function |
Timer and light Controlled |
Fit for |
Solar Home System, Solar Energy system, Solar Light, Solar Garden Light, Solar Power Supply etc |
Warranty |
One-year quality warranty |
Feature:
Using MOSFET Control Switch, Switching speed and low-power consumption, high-conversion efficiency.
Using Digital opt coupler circuits and control circuits, and strong anti-interference.
Complete protection: short circuit protection; reverse current protection; reverse polarity protection; lightning protection; overcharge protection; over discharge protection etc. System designed to reduce pressure loaded, no-load loss.
LED displays the relevant parameters of solar charge controller and work status.
Convenient wiring, simple installation without Day-to-day maintenance, service life is up to 20 years
Display: LCD
Dimension: 140×90×26mm
Weight: 0.26KG
