Help CenterROSH Approved Solar Controller Wind Generator Battery Charge Controller With Factory Price $7.5
Related Products
-
Electronic Solar Charger Controller With Timing and Lighting ControlUS$ 7.5 - 8.5MOQ: 30 Pieces -
12/24VDC Solar Charge Controller From ChinaNegotiableMOQ: 30 Pieces
-
10A Solar Charger Controller for Led Indicator Low CostUS$ 6.5 - 8.5MOQ: 30 Pieces
-
12/24V PWM Solar Controller 10A With CE RoHSUS$ 6.5 - 9.5MOQ: 50 Pieces
-
Mutifunctional Solar Charger Controller 12V/24V Auto With Battery IndicatorUS$ 6.5 - 8.5MOQ: 50 Pieces
Specifications
1.Solar charger controller2.System voltage 12V 24V/12V AUTO
3. PWM control model
4.Lighting and timing control
5.CE Rohs
ROSH approved solar controller wind generator battery charge controller
Technical parameters of the Solar Charge Controller :
Items |
Solar Charge Controller |
Model |
EPRC - 10LED – W EPRC - 20LED - W |
Rated Charge Current |
10A, 20A(12V/24V Auto) |
Rated Load Power |
10A Rated Voltage:12V:≤50W Rated Voltage:24V:≤100W 10A Rated Voltage:12V:≤100W Rated Voltage:24V:≤200W Note:Depend on the power of LEDs |
Constant power control precision |
>5% |
Overload, short circuit protection |
1.25 times rated current 60 seconds. 1.5 times rated current 5 seconds overload protection. |
System Voltage |
12V/24V Auto |
No-load Consumption |
≤6mA |
Recharge circuit reduction voltage |
≤0.26V |
Discharge circuit reduction voltage |
≤0.15V |
Overpressure protection |
17V, ×2/24V |
Ascending recharging voltage |
1.46 V, X 2/24V, Time 10min, (only when the discharge calls) |
Balanced recharging voltage |
14.4 V, X 2/24V, Maintain time :10min |
Floating charging |
13.6 V, X 2/24V, maintain Time: (until) voltage recharge returns |
Charging return volatage |
13.2v; ×2/24V(ascension, straight, floating and charging returns voltage compensation), |
Overcharging return volatage |
12.6 V, X 2/24V |
Out of volatage |
12.0V; ×2/24V; |
Overdischarge voltage |
11.1 V - the discharge rate consumption initial Over discharge voltage (no-load voltage), X 2/24V |
Temperature compensation |
-5mv/°C/2V |
Working temperature |
Industry-specific:-35°C~55°C(suffix I) |
Control Type |
Charging: PWMpulse width modulation, Output: Constant power |
Function |
Timer and light controlled |
Fit for |
Solar Home System,Solar Energy system,Solar Light, Solar Garden Light, Solar Power Supply, etc. |
Warranty |
One-year quality warranty |
Function & Feature of the Solar Charge Controller
1. Voltage: 12V/24Vdc
2. Current: 5A/10A/15A/20A/25A/30A for option
3. Solar controller water proof
4. Easy installation
5. Expected 10 years lifetime
6.2 year warranty
Control of the Solar Charge Controller
1. Charge and discharge control
2. Light Control
3. Time Control
4. Light and Time control
5. PWM Control
Electrical parameters of the Solar Charge Controller
1.System voltage:12/24VDC Auto work
2.Nominal battery current: 5A 10A 15A 20A 30A
3.Charge circuit voltage drop less than 0.26V
4.Discharge circuit voltage drop: less than0.15V
5.Self consumption: less than5mA
6.Battery voltage parameters
Applications of the Solar Charge Controller
Ideal for off grid solar system that loads are normally on or controlled by manual
1. Solar home system
2. Solar CCTV system
3. Solar traffic system
4. Wild automatic detection equipment.
5. Solar water pump system
6. Intelligent solar controller
7. For solar water heating system
8. etc
Photos of the Solar Charge Controller for refer
Why Buy From Us
1. 100% quality goods from factory(one world ,one price)
2. fully inspection before shipment, plus one year warranty.
3. Prompt customer support after selling service.
Payment&dispatching
1.We accept payment by Paypal, T/T, Western Union etc.
2.Generally, goods will be dispatched in 3-5 business days of receiving cleared payment.
Warranty and Guarantee
1. The products are fully test before delivery. We guarantee that the goods are of satisfactory quality. And we provide one year warranty.
2. Warranty is not covered for accident, water, abuse, misuse or other damage caused by abnormal usage.
Friendly tips : kindly check product before sign ( damage could happened during shipping) if any damage , let the courier return product . then contact us immediately, we’ll contact courier and solve the problem . Your 100% satisfaction is our unchangeable goals forever.
The above information is only for reference. Our R&D team can design the system according to the local natural resources and customers specific requirements.
