Popular 2.5m WER-S2508 Large Format Solvent Printer, Banner Printing Machine

US$ 12,000 - 12,300 MOQ: 1 Set

Key Specifications

Condition:

New

Plate Type:

Other, inkjey printer

Place of Origin:

Shanghai, China

Shanghai WER-China Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Plate Type Other, inkjey printer

Place of Origin Shanghai, China

Brand Name WER

Model Number WER-S2508

Usage Other, PVC Flex banner, vinyl sticker, mesh etc.

Automatic Grade Automatic

Voltage 220V(±10%)

Gross Power 2500W

Dimensions(L*W*H) 3.9m*0.77m*1.55m

Weight 500KG

Certification CE, EMC, LVD, SGS

After-sales Service Provided Engineers available to service machinery overseas

2.5m Banner Printing machine

Product Description

Print Technology	Drop-On-Demand Piezo Electric
Print Head	6 Heads (Seiko/Spt510-35pl)
Print Width	2.5 m width
Resolution	1440dpi Max
Print Speed	2 Pass 52 m2/h
	3 Pass 38 m2/h
	4 Pass 26 m2/h
	6 Pass 19 m2/h
Locating Mode	Raster strip/Raster sensor
Media Width	2.6 m
Color	C M Y K LC LM
Ink Type	Special ink for Seiko/Spt510-35pl
Ink	Solvent based Pigment Ink, at least two years outdoor durability
Ink delivery system	Ink force pumps auto supplying system, main ink case 1L/color
Media Handle	Roll to Roll
Media feeding &take-up system	Infra Red Optical Controlling System for Media Feeding & Take-up
Dry system	Pre/Post and Middle heater controlled by PID
Media Type	PVC Vinyl, Flex banner, Carpet Paper, PVC Mesh Fabric, Perforated Vinyl, Cloth Banner Etc.
Motor	Step Motor
Linear Rail	HIWIN
Height of Print-head	2 mm - 4 mm above media, adjustable
Print head maintenance facility	Protection trays for auto purge, daily maintenance and print heads over night
Auto-cleaning system	Double functional cleaning System of Pressure purge and Vacuum Suction
Interface	USB 2.0
Print Mode	Bidirectional Printing
File Format	TIFF,JPEG,Postscript 3,EPS,PDFRGB/CMYK
RIP Software	Original Maintop/Photo print Rip software
Working Process	Maintop software, Photo print software for Windows 98 and Windows XP Etc.
Power Supply	50HZ/60HZ, 220V(±10%)>15A
Filtration Facility	PALL filter + Regular ink filter
Operation Environment	Temperature: 23~29; Humidity: 50%~80%
