Home > Packaging & Printing > Printing Machinery > Digital Printing Machine > Digital Solvent Printer (2.5m*6 Heads Xaar 382-35pl)

Digital Solvent Printer (2.5m*6 Heads Xaar 382-35pl)

Digital Solvent Printer (2.5m*6 Heads Xaar 382-35pl) photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Other, outdoor solvent printer
Place of Origin:
Shanghai, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Plate Type Other, outdoor solvent printer
Place of Origin Shanghai, China
Brand Name WER, WER
Model Number XS2506, WER-XS2506
Usage Other, poster printer
Automatic Grade Automatic
Gross Power 2500W
Dimensions(L*W*H) 4.0m*0.7m*1.55m

Specifications

2.5m solvent printer has 6 pc of Xaar proton 382-35pl heads, 2 pass can print 45m2/h and the resolution can reach 1440dpi max





Print Technology

Drop on demand Piezo Head(XAAR382-35PL)

Print Head

6 Heads (XAAR382, fire frequency: 1014K)

Print Width

2.5m width

Resolution

1440dpi Max

Printing speed

2 Pass 37 m2/h

3 Pass 24 m2/h

4 Pass 18 m2/h

Locating Mode

Raster strip/Raster sensor

Media Width

2.6m

Color

C M Y K LC LM

Ink Type

Special ink for XAAR382-35PL

Ink

Solvent based Pigment Ink, At least tow years outdoor

Ink delivery system

Automatic liquid level sensor supplying system , Main ink case 5L/color

Media Handle

Roll to Roll handling

Media feeding &take-up system

Infra Red Optical Controlling System for Media Feeding &Take-up

Dry system

Pre/Post and Middle heater controlled by PID

Media Type

PVC Vinyl, Flex banner, Carpet Paper, PVC Mesh Fabric, Perforated Vinyl, Cloth Banner Etc.

Motor

Step Motor

Linear Rail

THK / HLWIN

Height of Print-head

2mm-8mm above media, Adjustable

Print head maintenance facility

Protection trays for auto purge, daily maintenance and print heads over night

Auto-cleaning system

Double functional cleaning System of Pressure purge and Vacuum Suction

Interface

USB 2.0

Print Mode

Bidirectional Printing

File Format

TIFF,JPEG,Postscript 3,EPS,PDFRGB/CMYK

RIP Software

Photoprint6.0 Rip software

Working Process

Photoprint6.0 software for Windows 2000 and Windows XP Etc.

Power Supply

50HZ/60HZ, 220V(±10%)>15A

Filtration Facility

PALL filter + Regular ink filter

Operation Environment

Temperature: 23~29; Humidity: 50%~80%
