2.4 inch QVGA tft lcd display with 320*240
Part No.: AT-T024SQI-XX
Display Format: 240RGB x 320(QVGA)
Outline Size: 42.72 x 60.26 with TP
TP Viewing area:38.72x54.16
TP Active Area:37.72x53.16
LCD Active Area: 36.72 x 48.96
LCD Type: 2.4 inch QVGA TFT LCD
Backlight: 4 parallel white LED
Controller:ILI9341V
Operation temperature:-10~60degree
Storage temperature:-20~70degree
TFT PACKAGE:
1.Put module into tray cavity.
2.Tray stacking.
3.Put 1 cardboard on the top and bottom of tray stack.
4.Fix the cardboard to the tray stack with adhesive tape.
5.Put the tray stack into carton with filler.
6.Carton sealing with adhesive tape.
With the strength of skilled engineers and own factory, we supply ODM service to meet your customized needs.
Main Product:
TFT module (1.77-10.4inch), special size TFT, MVA TFT, sunlight readable TFT, anti-reflective glass, optical bonding, CTP, LCD panel, LCD module etc.
Application:
automotive, security products, industrial instrumentation, medical equipment, terminal equipment, smart home.
Certification:ISO9001 ISO14001 RoHS
A-Tops Electronics Co.,Ltd was found in 1998 and consists of LCD Panel factory, TFT factory and CTP factory. We specialize in design, manufacturing, and supply of high quality LCD products. With 16 years experience and development, A-TOPS has grown to be a leader in display which offers customers with perfect solution, high quality and after-sales service.
Other Products Range:
1.Standard COB & COG Character/Graphic LCD Module,
2.Customized TN/HTN, STN, FSTN LCD as Customer's drawing
3.TFT lcd module from 1.77"~10.1", Counter, Timer, VA products and so on.
For more details pls visit our website /
