Specifications
Machine Cut Paper1.Vertical And Horizontal A4 Paper Cutting Machine
2.100times/min
3.PLC,Servo Motor
4.In Stock
High Quality A4 Automatic Machine Cut Paper Usage:
This machine Cut Paper is suitable for cutting the large coil packaging material,such as the paper, papaer plastic complex material and color printing complex material,etc This machine is widely used for application in the industries of paper processing and printing packaging.
Automatic Machine Cut Paper Function:
1,This machine adopts the servo motor (or stepless motor) to control the fixed-length cutting .It is equipped with the photoelectric tracing modifying system.
2,This machine integrates photo. electricity liquid and as a whole, PLC touching screen (manual or antomatic), and has the features operation,high-precision cutting,state operation and low noise.
3, The machine has the fenture of the motor frequency speed adjustment.
4.automation counting, giving an alarm when stop. and tension with digital indication.
A4 Machine Cut Paper Main technical parameters:
Model parameters |
DKHHJX-1100 |
DKHHJX-1300 |
DKHHJX-1600 |
||
maximum diameter of raw materials |
1400mm |
1400mm |
1400mm |
||
The largest-cut width |
1100mm |
1300mm |
1600mm |
||
The accuracy |
20-1200mm |
20-1200mm |
20-1200mm |
||
Precision of fixed |
±0.2mm |
±0.2mm |
±0.2mm |
||
Productivity |
100 m/min |
100 m/min |
100 m/min |
||
Total power |
11kw |
13kw |
15kw |
||
Weight |
2300kg |
2600kg |
3000kg |
||
Applicable power |
380v/50Hz(three phases four wire) |
||||
Dimensions (mm) |
5500×1850×1200 |
5500×2100×1250 |
6000×2400×1250 |
||
Skype: ritayuan99
The machine Real Pictures:
Cutting Paper Machine Magnetic Tension Control:
The Round Knife for Vertical Cutting
Finished A4 Paper Automatic Sorting :
Machine Cut Paper Complete Line: In Stock
A4 Machine Cut Paper In stock Welcome Contact me or Visit us Anytime
We also can customized according the customer's require
