Stranded Loose Tube No-metallic Strength Member -Armored CableⅡ(GYFTA53)
Product details
The fibers, 250µm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. A Fiber Reinforced Plastic (FRP) locates in the center of core as a non-metallic strength member. The tubes (and fillers) are stranded around the strength member into a compact and circular core. An aluminum Polyethylene Laminate (APL) is applied around the cable core. Then the cable core is covered with a thin polyethylene (PE) inner sheath, which is filled with jelly to protect it from water ingress. After a corrugated steel tape armor is applied, the cable is completed with a PE outer sheath.
Characteristics
Good mechanical and temperature performance
High strength loose tube that is hydrolysis resistant
Special tube filling compound ensure a critical protection of fiber
Crush resistance and flexibility
The following measures are taken to ensure the cable watertight:
Single Fiber Reinforced Plastic as the central strength member
Loose tube filling compound
100% cable core filling
APL moisture barrier
PSP enhancing moisture-proof
Water-blocking material
Standards: IEC 60794-1
Technical Parameters.
Part No. |
Fibers |
Tubes |
Cable OD (mm) |
Weight Kg/km |
Tensile strength Long term/short term (N/1m) |
Crush resistance Long term/short term (N/1m) |
Bending Radius Static/Dynamic (mm) |
GYFTA53-2~6X |
2~6 |
1 |
16.8 |
255 |
1000/3000 |
1000/3000 |
10D/20D |
GYFTA53-8~12X |
8~12 |
2 |
16.8 |
255 |
1000/3000 |
1000/3000 |
10D/20D |
GYFTA53-14~18X |
14~18 |
3 |
16.8 |
255 |
1000/3000 |
1000/3000 |
10D/20D |
GYFTA53-20~24X |
20~24 |
4 |
16.8 |
255 |
1000/3000 |
1000/3000 |
10D/20D |
GYFTA53-26~30X |
26~30 |
5 |
16.8 |
255 |
1000/3000 |
1000/3000 |
10D/20D |
GYFTA53-32~36X |
32~36 |
6 |
16.8 |
255 |
1000/3000 |
1000/3000 |
10D/20D |
GYFTA53-38~42X |
38~42 |
7 |
16.8 |
255 |
1000/3000 |
1000/3000 |
10D/20D |
GYFTA53-44~48X |
44~48 |
8 |
16.8 |
255 |
1000/3000 |
1000/3000 |
|
GYFTA53-50~60X |
50~60 |
5 |
19.2 |
320 |
1000/3000 |
1000/3000 |
10D/20D |
GYFTA53-62~72X |
62~72 |
6 |
19.2 |
320 |
1000/3000 |
1000/3000 |
10D/20D |
GYFTA53-74~84X |
74~84 |
7 |
19.2 |
320 |
1000/3000 |
1000/3000 |
10D/20D |
GYFTA53-86~96X |
86~96 |
8 |
19.2 |
320 |
1000/3000 |
1000/3000 |
10D/20D |
GYFTA53-98~108X |
98~10 8 |
9 |
21.2 |
380 |
1000/3000 |
1000/3000 |
10D/20D |
GYFTA53-110~120X |
110~120 |
10 |
21.2 |
380 |
1000/3000 |
1000/3000 |
10D/20D |
GYFTA53-122~132X |
122~132 |
11 |
22.3 |
415 |
1000/3000 |
1000/3000 |
10D/20D |
GYFTA53-134~144X |
134~144 |
12 |
22.3 |
415 |
1000/3000 |
1000/3000 |
10D/20D |
Note:
Suffix X denotes fiber type.
The nominal value of the PE outer sheath thickness is 1.8mm. The nominal value of the PE inner sheath thickness is 0.8mm.
Packaging
one piece in a platic bag.
Several bags in a carton of 54*39*35cm
