pet washed machine
plastic recycling line is used to make recycled PET bottle in to clean flakes. After drying the material can be use for granulating and make products.
The main components of the machine including:
-Project summary: |
|
||
NO. |
Item. |
Spec. |
|
1 |
Material |
Waste PP HDPE bottles baled pressed/round bottles size 0.5-5L |
|
2 |
Capacity |
output: 700-800 kg/hr |
|
3 |
Final products size |
12-60mm |
|
4 |
Electricity power supply |
380V 50HZ 3P or Customized |
|
5 |
Installed power |
350 KW for whole plant |
|
6 |
Power consumption |
60% of installed power |
|
7 |
Water supply |
The buyer supply the water connection pipes; The buyer should have the pools and water tower for the water supplying to the machine; The buyer can buy the waste water treatment system machine from us to recycling use the water; |
|
8 |
Water consumption |
5-10 T/hr, but can recycling use upon build the filtering tank or water treatment equipment by buyer; 2-3T water consumption If online recycle use the water |
|
9 |
Plant area |
1000 Square meter 4 meter height Estimate line size: 85 m(Length)* 5 m(width)* 3 m(Height) we can make the line turn as U or L shape to fit the buyer's plant |
|
10 |
Heating for hot washing |
heating by electricity |
|
11 |
Manpower: |
10-15 Persons required |
|
12 |
Final flakes quality |
- Surface moisture: max. 2 % - PVC content: max. 500 ppm(According to your worker sorting) - Glue content: max. 4.000 ppm (Flakes included) - Label content: max. 500 ppm(According to your worker sorting) - PH-value: neutral - HDPE / PP content: max. 500 ppm - PET dust: max. 0.1 % - Metal content: max. 50 ppm - Coloured flakes: max. 500 ppm(According to your worker sorting) - Yellow flakes: max. 4000 ppm(According to your worker sorting) - Other contamination: max. 50 ppm(According to your worker sorting) |
|
Work flow of pet bottle recycling line
Conveying raw material→Crushing with water→ Feeding →No.1 Rising washer→Feeding →Agitating
washer→Feeding→Horizontal frication washer →No.2 Rising washer →Feeding→No.3 Rising Washer→Feeding
→Dewater machine→Pump conveying system→Hopper
l Our LY pet bottle recycling line
is used to treat solid plastic material,just like pet bottles,pp/pvc barrels and so on.
l It can crush,wash,and dry the material,finally you will get clean,dry flakes,which can be used to make granules directly or some other use.
Features
Our LY company adopt European criterion designing and manufacturing, CE marked.
l Simple to operate and service- 2-3 workers are capable for operation
l Enviromental friendly process, no secondary pollution output
l Optional for waste water retreatment
l Little water and electricity consumption
l Relatively low initial investment
Quality control:
- Fixed Equipments for Q/C
- Professional team of Q/C
- Qualified successfully before get in warehouse
- Randomly Checking Machines before shipment
Packing and shipping
Servce system
Pre-sale for PET Bottle Washing Line :
We provide presales service in various forms, for example, making investment budget,manufacturing
planning, etc. so that customers make a reasonable plan with less cost.
• Investment budgeting: We provide services of product profit analysis, recommendation of machine
and auxiliary equipment and relevant budgeting, human resources allocation and budgeting.
• Plant Planning: We provide the mounting dimension of the equipment base,design of equipment
layout, workshop ventilation, water transmission etc.
• Offer information of peripherals
In-sale for PET Bottle Washing Line :
• Detailed design of lay-out that is the position of the procession
• Technological information of provided products
• Schedule about design,manufacturing and installation
• Working & Producing progression
• Training course for the technician so that the installation is safe and standard
After-sale for PET Bottle Washing Line :
• For customers buying our products, we provide them free training so that they can use and maintain
the machine independently.
• We will answer customer's question on technology in time. If needed, we will offer on-site guidance
and assistance.
• We can provide free technical guidance if customers need new equipment, add or rebuild equipment.
• We will prioritize the product upgrade of former customers.
