SAHARA series
KDO55 Vertical outdoor LCD display
Display categories: Liquid crystal
Resolution: 1920x1080(16:9)
Size: 55”
The main features: high brightness modular design Fast dissipation
Parameters
Series |
Type |
KDO55 Vertical outdoor LCD display |
Panel |
Size |
46” |
Backlight |
LED |
|
Resolution |
1920*1080 |
|
Brightness |
2000 cd/m2 |
|
Contrast Ratio |
4000:1 |
|
Response time |
5.5ms |
|
Viewing angle |
178°/178° |
|
Colors |
1.07B(8bit+FRC) |
|
Color saturation |
75percent |
|
Display direction |
Transverse , longitudinal |
|
Service life |
50000hours |
|
Power Supply |
Power input |
AC 208~240V |
Average power |
600W |
|
Power range |
400-1200W |
|
Working environment |
Working temperature |
-40℃~+55℃ |
Working humidity |
5percent~100percent |
|
Physical specifications |
Texture of material |
Full metal housing appearance design, carried excellent heat conducted material |
Dimension(W×D×H) |
840mm ×250mm ×1910mm |
Unique structural design
Waterproof, dustproof, anti-theft outdoor LCD display
Outdoor LCD display security anticorrosion more than 8 years
Fully modular design, easy installation and maintenance
Safety glass , high transmittance of ultraviolet antireflection without ultraviolet light.
Optical system design
1500-3500cd/m2high brightness LCD display
LED backlight, environmental protection and energy saving
Auto-adjust the brightness according to the environment light
Leading short wide-angle LED light bulb in the world
Higher luminous efficiency, more energy saving (55", 2000 cd/m2 400W)
Environmental control system design for LCD display
Intelligent air conditioner, integrated heating and cooling
LCD display outdoor working environment temperature -40-50℃
Heat dissipation design of patent technology
Direct sunlight without blackening liquid crystal screen
The efficient third generation of water aluminum foil radiator, improve heat dissipation performance
R134a R410a environmental protection cooling medium
The monitoring machine internal operating environment
Product system testing
Design and manufacture of the communication industry cabinet and temperature control system, design and manufacturing experience of military heat d system.
Unique full outdoor environment simulated laboratory in the field (high temperature low temperature rain dust sunshine)
Strict testing and degradation testing before go out, 100% waterproof and dustproof testing , 24 hours overall aging.
Company information:
Keewin was founded in September 2004 , headquarter in Shanghai, branch in Shenzhen and factory in Suzhou. We have engaged in distribution of LCD panel, Open Cell, optical and electronic materials since 2004. We professional develop and produce ultra-high brightness LCD panel and outdoor LCD display device. Provided the industry standard and custom properties commercial display solutions to industrial users. The company has formed "information exhibition ". "security monitoring“. "exhibition" and other categories of industry competitive display products and solutions, Including: outdoor advertising display, high brightness digital signage, narrow Bezel LCD splicing wall, special-shaped screen, information broadcasting system , customize display terminal, Be widely used in media, public transportation, chain store, hotel, education, CBD commercial district , parks etc. Keewin owned a bold innovation, strong technical force, strong technical expertise. The company has filed a patent in Patent Office of China for its invented new structure and technology in high brightness LCD module, patent filing number: 201410273054.5. The company held a production facilities of 8000 square meters in Suzhou. Its main products include the high brightness LCD panel, high brightness outdoor advertising display. The company is able to provide full industry solutions, one-stop service for all the customer's display needs . We are not only meet the large-scale demands of mass production, but also can provide personalized service and products to meet your needs . We are not only pay attention to technology innovation and product quality, but also focus to the pre-sale, sale and after sale service. We committed to provide the best service to our customer
