mica paper capacitor with high voltage
(High temperature,high voltage)
Feature:
Using the best mica paper 511 as material,dipping high temperature epoxy resin.
As the high insulated resistance,low coefficient,good high frequency performance.
Very low dissipation factor <5x10-3 (min 1x10-4).
Very stable at high temperature, small capacitance tolerance.
After storage 15years, capacitance change not over ±1%.
General Characteristics
Temperature Range: -55℃~+200℃
Capacitance Tolerance: ±3%,±5%,±10%
Relative Humidity: at +40℃ can be 95~98%
Atmospheric pressure: 4x104Pa
Vibration: frequency 20~200Hz, acceleration: 2.7~4.5g
Working voltage: 0.45KV~30KV
DC test voltage: After keep 1 hour at +150℃,loading 1.5times working voltage 1 minute,no breakdown and flashover.
Insulation resistance(R): normal climate
Capacitance C ≥ 0.1μF R≥1000MΩ
Capacitance C< 0.1μF R>5000MΩ
Application:
Our CVG series mica pcapacitors are suitable to high frequency,high voltage,high temperature,big current circuit. Like high frequency feedback circuit,high frequency resonance circuit and pulse circuit etc.
Widely use in satellite,aerospace,ship,medical equipment,oil down-hole equipment,welding machine,metallurgy equipment etc.
|
Shanghai Green Tech is high quality passive components supplier and energy storage system solutions provider. And has been providing various capacitors to electronic industry with GTCAP brand since 2005.
|
| |
| |
