RPLT 1600S Light Tower

Name: RPLT 1600S Light Tower
Brand: RP186FA Diesel
SKU: 134530781

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

RP186FA Diesel

Model Number:

RPLT1600S

Fujian Robust Power Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB Fuzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name RP186FA Diesel

Model Number RPLT1600S

Output Type AC Single Phase

Speed 50HZ 3000RPM 60HZ 3600RPM

Frequency 50HZ/60HZ

Rated Power 4.2KW/50HZ 5.0/60HZ

Rated Voltage 120V 220V 230V 240V

Specifications

Mast:4.8m(Mechanical/e)/Winch/358 degrees
Metal halide lamp/4x400Wt/220V
Ring or ball hitch

Model RPLT1600S
Technical Specifications
Mast
Maximum extention of mast	4.8m
Elevation	Manual
Raising/lowing mast	Winch(Mechanical)
Stages	2
Turning angle	358 degrees non-continuous
Lamp
Total power of lamps	4×400W / 4X1000W
Type of lamp	Metal halide lamp
Light capacity	4×25000 lumen
Voltage	120.220.230.240
Frequency	50Hz/60Hz
Lifetime of lamp	2000 hours
Working temperature	≤85Degrees Celsius
Connection Protection index	IP54
Characteristics of the generator
Model	RPD6500I(Made in China)
Generator set Prime power	50Hz 4.2kW 60Hz 5.0kW
Engine model	RP186FA Diesel
Engine speed	50Hz 3000rpm 60Hz 3600rpm
Engine type	1 cylinder,4-stroke,Air-cooled
Starting system	Recoil & Electric
Alternator Type	2-pole, brushless
Fuel tank capacity	15L
Prime fuel consumption at 100% load	1.85L/h
Working hours	8
Control system	Digital control panel
Power Outlets	2
Trailer
Stabilier Supports	4 × Manual
Tire Size	25cm
Anti-wind capacity	≤6
Brakes	Manual
Packing Dimension & Weight
Retracted Dimension	1360mm × 830mm × 2600mm
Container load (20/40FT)	12/27(At least)
Net weight	270kg
