Light Tower Alternator
US$ 5,000 - 8,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Robust Power
Model Number:
RPLT8000
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
9m Industrial Mobile Light Tower /big Power Diesel Generator SetUS$ 5,000 - 8,000MOQ: 1 Set -
50kw Deutz Generators SoundproofUS$ 2,000 - 8,000MOQ: 1 Acre
-
RPLT8000 Indudstrial Mobile Lighting TowerNegotiableMOQ: 1 Set
-
RPLT8000 Indudstrial Portable Lighting TowerUS$ 1 - 21MOQ: 1 Set
-
Telescopic Light Tower RPLT8000NegotiableMOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
Robust Power
Model Number
RPLT8000
Output Type
AC Single Phase
Speed
1500/1800rpm
Frequency
50/60Hz
Rated Power
24KV
Rated Voltage
120, 220, 230, 240V
Rated Current
Voltage
24KV Industrial Movable Lighting Tower
| Technical Specifications | |
| Mast | |
| Maximum extention of mast | 9m |
| Elevation | Mechanical/ Electric |
| Raising/lowing mast | Winch(Mechanical)/ Button(Electric) |
| Stages | 3 |
| Turning angle | 358 degrees non continuous |
| Lamp | |
| Total power of lamps | 4*1000W |
| Type of lamp | Metal halide lamp |
| Light capacity | 4*88000 lumen |
| Voltage | 120,220,230,240 |
| Frequency | 50HZ / 60HZ |
| Lifetime of lamp | 5000 hours |
| Working temperature | ≤85°C |
| Connection protection index | IP54 |
| Light Coverage | 5-7 acres |
| Characteristics of the generator | |
| Model | RD20C |
| Rated power | 50HZ 20KW 60HZ 23KW |
| Standby power | 50HZ 22KW 60HZ 25KW |
| Engine model | Cummins 4B3.9-G1 Diesel |
| Engine speed | 50HZ 1500RPM 60HZ 1800RPM |
| Engine type | 4 cylinder, in line, water-cooled |
| Engine aspiration | Turbo charged |
| Alternator | 4-pole, brushless |
| Fuel tank capacity | 70L |
| Prime fuel consumption at 100% load 1.85L/h | 5.6L/H |
| Maximum working hours | 12 |
| Control system | T201 digital controller |
| Power Outlets | 3 |
| Trailer | |
| Tow hitch | Ring or ball hitch |
| Stabilier Supports | 5*Manual |
| Tire Size | 70cm |
| Anti-wind Capacity | ≤10 |
| Brakes | Manual |
| Packing Dimensions & Weight | |
| Retracted Dimension | 4400mm*1450mm*2100mm |
| Net weight | 1500kg |
