Home > Construction & Decoration > Fence > Security Fence > Protection Coil Cable Lock

Protection Coil Cable Lock

Name: Protection Coil Cable Lock
Brand: guofeng
SKU: 134594725

US$ 1.5 - 1.5 MOQ: 500 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

guofeng

Model Number:

other

Contact Supplier Request Quote Chat Now

Dongguan City Guofeng Sports Equipment Fitting Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name guofeng

Model Number other

Product Description

protection coil cable lock

1.Diameter	0.7-11mm	Custom-made available
nstruction	17,77,119,719,etc
3.material	galvanized steel or stainless
4.MOQ	500pcs
5.length	as required
6.loop	as required
ating	clear PVC/PU/PA
8.end parts of fittings	a large selection of end fittings,including eye bolts,links,springs,hooks,thimble,clips,stops,ball ,ball shanks ,sleeve ,stamped eye,handles,etc
9.Lead time	7days if there were enough material in stock
10.sample	Free sample available if all of dimensions same as our existing one ,if not ,contact me ,to get a cost efficient solution.
application	Lighting , Machinery, Medical, Security, Sporting Goods, Toys, Window , Lawn & Garden Etc. When designing a cable assembly, a number of factors need to be considered such as, work load, abrasion, cycle life, and flexibility, environment, cost, safety .etc. the larger the diameter ,the greater the work load capacity and the less flexible it will be. WARNING :Breaking strength should never be considered the rope's working load ,safety factor 5:1 ,Coating must be removed from installation area when attaching fittings
specification	Refer to the drawing as below: All of specification custom-made available. the tighter tolerance ,the higher the cost of the cost.

Diameter	construction	weight(100m)	Minimum Breaking load(N)
1.0mm	1*19	0.495	950(95kg)
	7*7	0.393	650 (65kg)
1.2mm	1*19	0.713	1440(144kg)
	7*7	0.566	950(95kg)
1.5mm	1*19	1.114	2200(220kg)
	7*7	0.884	1500(150kg)
1.8mm	1*19	1.604	3200(320kg)
	7*7	1.273	2100(210kg)
2.0mm	1*19	1.98	3900(390kg)
	7*7	1.527	2650(265kg)
2.4mm	1*19	2.851	5650(565kg)
	7*7	2.264	3800(380)kg
2.5mm	1*19	3.094	6100(610kg)
	7*7	2.381	4100(410kg)
3.2mm	7*7	4.024	6850(685kg)
	7*19	3.901	6800(680kg)
3.8mm	7*19	5.675	9650(965kg)
	7*7	5.502	9600(960kg)
4.0mm	7*19	6.609	12500(1250kg)
4.2mm	7*7	6.933	13000(1300kg)
4.5mm	7*7	7.958	13500(1350kg)
4.8mm	7*19	8.778	15300(1530kg)
6.0mm	7*19	8.716	23900(2390kg)

how to choose material:1stain1.1.1.

1.stainless steel :

providing good corrosion resistance and strength comparable to galvanized carbon steel grades.

2.galvanized steel:

Zinc coated carbon steel offers some corrosion resistance. It remains ductile over long periods of working. Usually higher break strengths than stainless steels.

our service and FAQ
