Help CenterBottle Unscrambler
Related Products
Specifications
1. suitable for unscrambling disordered polyester bottles.2.Automatic bottle unscrambler
3.PLC Contral
4.CE
APPLICATION:
This machine is suitable for unscrambling disordered polyester bottles. The disordered bottles are carried into the storing-section of the ordering bottle machine, and with the help of the pushing force of the rotating disk, the bottles enter their position. With the function of the turning-bottle device and the air-flow, the bottles are ordered into bottle mouth-up-position and are carried into the next process with the air-transfering type conveying bottle system. The machine adopts PLC computer system, and its frequency-control system can adjust its production capacity.
Production capacity |
500 ml - 20000 bph |
Gas Source pressure |
0.7 Mpa |
Gas consuming volume |
0.5 m3/min |
Suitable bottle type |
Ø50-Ø90 |
Power |
2.20kw |
Size |
Ø2650x2290mm |
Weight |
5800kg |
