ED208H65-T3 2U Rackmount Chassis for data center:
Model No.: |
ED208H65-T3 |
||
Description: |
2U 650mm depth, Hot Swap 8 x 3.5”HDD, 2 x 2.5” HDD, 1 x Slim-DVD |
||
Material: |
1.2mm SGCC |
||
M/B Form Factor: |
12” x 13”, 12” x 10.5”, 12” x 9.6” |
||
Processor: |
DP Xeon (Intel), DP Opteron(AMD), Core (Intel) |
||
Support Backplane: |
Sata III/mini sas |
||
Expansion Slots: |
4/6 |
||
System Cooling (Shockproof): |
Middle: 4 x 8025mm (hot swap) |
||
Chassis Dimension: |
650mm(D) x 430mm (W) x 88mm (H)/D25.6” x W16.9” x H3.5” |
||
Drive Bay: |
3.5” (Hot Swap) |
8 |
|
2.5” |
2 |
||
CD-ROM |
1 |
||
Power Supply: |
Standard 2U power/Redundant 1+1 power |
||
Rear Window: |
Standard |
||
Front Panel: | |||
Front Control: |
Power on/off, System Reset, Alarm Reset |
||
Indicator: |
Power LED (x1), HDD Activity LED (x1), LAN Activity LED (x2), Fan/Power Failure LED |
||
Ports: |
USB 3.0 x 2, VGA (option) |
||
Pictures :
Our factory(Dongguan):
Wangjiang Office:
Songshan Lake Branch Factory:
