12V LED Display DC-DC Power Supply 24V to 12V Car/Vehicle Step Down Buck Converter Voltage Regulator Waterproof
US$ 5.29 - 6.49
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
24V to 12V car power supply
Model Number:
24V to 12V car power supply
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN/HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Car/Vehicle Power Supply 24V to 5V/6A 12V to 5V/6A Power Converter Voltage Regulator Waterproof LED Display DC-DCUS$ 3.99 - 4.69MOQ: 1 Piece -
Boost Converter Step-Up Module Power Supply 600W DC-DC 12V-60V to 12V-80VUS$ 11.19 - 12.69MOQ: 1 Piece
-
NC DC-DC Adjustable Regulators Power Supply Module Buck Module Step Down ModuleUS$ 7.89 - 8.77MOQ: 1 Piece
-
DC-DC 4.5-24V High Efficiency Synchronous Rectifier Buck Power Converter Voltmeter Power Supply Module With Digital TubeUS$ 4.68 - 6.51MOQ: 1 Piece
-
AC-DC 5V Power Module 5V 2.5W 500MA Switching Power Supply Module Step Down ConverterUS$ 1.92 - 2.66MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
24V to 12V car power supply
Model Number
24V to 12V car power supply
1. Products Feature
1). This module has synchronous rectification. And the efficency is up to 96% with low calorific value.
2). The function of this module hasover-curren protection and short-cirsuit protection. It can work normally after remove away the problems. But it has no reverse polarity protection. so Don't conect it reversely.
3). This module has:waterproof! Dustproof! Shockproof! Three function integrate with one, USES the high quality transparent epoxy glue potting.
4). Can be widely used inbus, large trucks, cars, solar power, bus display, taxi advertising screen, etc. it never influence car ridio,the stereo, LCD TV, LED, car navigation, walkie-talkie and monitoring system, easy to deal with the bad environment.
2. Products Data
1). In+: Red Wire
2). In-: Black Wire
3). Out+: Yellow Wire
4). Out-: Black Wire
5). Weight: 72g
6). Three wires: 15cm
7). Output ripple: 50mV(MAX)
8). Dimensions: 46*33*22mm(length*width*height)
9). Input voltage: 17-40V(24V is the perfect voltage)
10). Output voltage: 12v
11). Output current: 6A
12). load regulation: ±1%
13). Voltage regulation: ±2%
14). Working temperature: -20degree - +85degree (industrial grade) (When the temperature is more than 40 degree, please use it in low power or strenth heat dissipation)
15). Conversion efficiency: 96%
16).The low pressure differential: 5V
