Specifications
suitable for LDPE,HDPE,LLDPE biodegradable film rolls
WHY US?
The Quality We Provide - Outstanding Quality Assurance
Control from production process:
•We don’t send mechanical parts out for pretreatment, all process would be supervised under inspection
department, we have 4sets CNC processing machine.
•7 stages pretreatment meet international standard
•Baking at high temperature after power coating to ensure the paint finish
Control from material:
•All bolts and screws are of SS material
•Mild steel ERW rectangular tubes or sheets 1.2-2.0mm thickness, meet EU standard
•Plastic material is of ABS only. Durable and Sturdy. At least 10 years lifetime. Different colors for options.
Control from inspection:
•Process inspections after cold working, acid washing,powder coating and assembling
Final inspection before loading in random checking
The Service We Provide - We Take Care Of Your Order
Punctual delivery time:
•We put your order into our tight production schedule, ensure your punctual delivery time.
•Production / inspection report before your order packed.
•Shipping notice/ insurance to you as soon as your order is shipped.
After sales service:
•We respect your feed back after receive the goods.
•We provide 12-24 months warranty after goods arrive.
•We promise all spare parts available in lifetime use.
•We respond your complain within 48hours.
Professional sales:
•We value every inquiry sent to us, ensure quick competitive offer.
•We cooperate with customer to bid tenders. Provide all necessary document.
•We are a sales team, with all technical support from engineer team
For machine services:
1.Installation Services are available with all new machine purchases. We will provide the technical know-how for your operation smooth transition and support for installing, debugging, operation of the machine, it will indicate you how to use this machine well.
2.We can train your staff to use new equipment systems properly. It means that we offer Customers Training, teaching how to use the systems most efficiently and safely as well as how to maintain optimal operational productivity in the condition of salary 80USD per day,also including the charge for transportation,accomodation,etc.
High Speed PE film blowing extrusion machine ,LDPE,HDPE,LLDPE
Performance and Characteristics:
It is used for blowing various plastic film of low density polyethylene(LDPE),high density polyethylene (HDPE)and linear low density polyethylene(LLDPE)etc., Which are widely used for packing liquid, industrial products, garments and textile and printing lamination etc. The cylinder and the screw stems of the extruder are made of high-quality alloy steel with optimum hardness and strong corrosion resistance after nitrogen treatment and precision finishing.
The auxiliary machine has a platform working table for making operation easy and is equipped with double stabilizing ring. Double-rolling and double-cutting coiling unit adopts torque motor to keep proper tension and make even and roll-changing easy.
Main Technical Variables:
Model |
H50 |
H55 |
H60 |
H65 |
Diameter of screw |
50 |
55 |
60 |
65 |
Reduced diameter of film(mm) |
100-600 |
200-800 |
300-1000 |
400-1200 |
Single-face Thickness of film(mm) |
0.008-0.06 |
0.008-0.06 |
0.008-0.06 |
0.008-0.06 |
Max.output(kg/h) |
25-30 |
35-40 |
60-65 |
65-70 |
L/D |
28:1 |
28:1 |
28:1 |
28:1 |
Power of main motor(kw) |
11 |
15 |
18.5 |
22 |
Power of Traction motor(kw) |
1.1 |
1.1 |
1.5 |
1.5 |
Heating Power(kw) |
13 |
15 |
21 |
23 |
Overall dimension(L×W×H)(mm) |
5500×2000×4200 |
5800×2200×4500 |
6300×2500×5200 |
6800×7800×6300 |
Weight(T) |
1.5 |
1.8 |
2.2 |
2.5 |
