Specifications
small hardware packing machinery1. PLC & HMI
2.Automatic weighing, filling
4.Hot melt sealing
5.Count the finished product
small hardware packing machinery
The machine can finish all action automatically like weighting ,filling ,glue-spraying and sealing ,and can count finished products.
Feature
Adopt international famous brand of electrical component such as PLC
Adopt human machine operation system
Serve feeding suitable for different specification Alu/PVC blister
Automatically stop when machine overload
Automatically reject lacking pf package products and leaflet
Automatically display trouble ,alarm and counting
Main Technical parameters
Speed |
50-100 box/min |
box size |
(45-280)mm×(20-170)mm×(14-80) mm |
Available paper |
250-500g/sm (according to the dimension to confirm) |
Air pressure |
0.6-0.8Mpa |
Air consumption |
120-160L/min |
Power |
AC 380V 50HZ / 220V 60HZ |
Max power |
4kw ( single match power supply) |
Motor power |
0.75kw |
Overall dimension |
3100mm×1100mm×1600 mm (L×W×H) |
Weight |
1600kg |
Some parts of the machine
Hot melt glue machine
Samples
