Specifications
NTL-6000 ROOM THERMOSTAT- LED indicator
- with manual switch and knob
- on/off control
NTL-6000 ROOM THERMOSTAT
The NTL-6000 is used for 2-position control with on/off output for the control the temperature by means of an NTC sensor Placed externally or internally in the thermostat
The thermostat acquires the room temperature with its built-in sensor or floor sensor. And the heating contact will close when the room tem Perature falls below theselected setPoint
Application
For the control of warm-water(floor) heating systems and direct electric heating systems used in Commercial buildings, Residential buildings, Light industrial buildings
Features
- LED indicator is light when heating is on
- with manual switch and knob for easy operation
- on/off control output for heating device
Technical data
- Voltage: AC230V
- Power consumption: 5W
- Setting range: 4ºC-45ºC
- Switching differential: 0.5K
- Ambient temPerature: -5ºC-50ºC
- Protective housing: IP20
- Housing material: Self_extinguishing PC
- Floor sensor: Rubber-thermoplastic NTC sensor
- Cable length is 3m
