Help CenterVantilator 550mm
Related Products
-
High Quality Cast Iron Blade Paint Booth FanUS$ 25 - 250MOQ: 1 Piece -
Round Tube Axial Fan Hot Air Exhaust FanUS$ 20 - 75MOQ: 5 Pieces
-
Round Tube Axial Kitchen Window Exhaust FanUS$ 20 - 75MOQ: 1 Piece
-
Round Tube Axial Bathroom Window Exhaust FanUS$ 20 - 75MOQ: 1 Piece
-
Round Tube Axial Ceiling Fan With Hidden BladesUS$ 20 - 75MOQ: 5 Pieces
◊ Product picture
◊ Drawing
◊ Specification
◊ Model Description
YWF |
4 |
E |
- |
400 |
S |
- |
5 |
L |
- |
G |
1. |
2. |
3. |
|
4. |
5. |
|
6. |
7. |
|
8. |
1.YWF-External Rotor Axial Fan
2.Motor pole number:2-2poles,4-4poles.6-6poles,8-8poles
3.D:3-phases motor,E-single-phase motor
4.Blade diameter:400-blade diameter is 400mm
5.Wind code:S-induced draft,B-blow
6.Blade number:5-5blades
7.Wind leaf shape:L--falciform,F--aquare type,LT--continuum
8.Fan type:G-pipeline gaotong,A-short barrel,
Fa-terms of frame short barrel,Fg-aspects box
Gaotong,W-meshenclosure type.
◊ application
Due to the features of high efficiency,low noise,low vibration,short axial length and maintenance-free,this series fan can be used in a broader application scope including in the fields of air-conditioning,refrigeration,ventilation and etc.
This series of motor is applicable for an environment temperature among-30°C-60°C,with an altitude below 1000 meters.
◊ Features
1.29 years production experience
2. high efficiency,low noise,low vibration,short axial length and maintenance-free
3.100% copper wire
4.1 year warranty
5.CCC,CE
◊ Company Introdution & Production Process
