Specifications
Application:Used in color or round band-aid production packaging.Feature:Use of frequency control,high speed,automation.
Usage
Suitable for elastic fabric,cotton fabric,PVC,PE,Spunlace fabric,non-woven fabric etc.materials cut pastes production packaging.
Product Features:
1.Use of frequency control devices,so that it is easy to adjust the speed of production.
2.KC-360N-A model uses Multi-floating roller buffer device,so that the anti-adhesive paper and the tape are steady while towing-stripping-compounding at high speed,reducing the deformation fight wrinkles and the damage to the tape.
3.The machine using light-control switch to control solenoid,so it can change the number of products to cut off automatically.
4.KC-360N-A model can easily adjust the working condition of tape,pinhole,medicine belt and wrapping paper to the correct location.
5.KC-360N-A model's drug pad feeding and tape walking are in the same direction.
6.Machine drive adopts timing belt wheel drive mode.The equipment is smoothly when it is in high-speed operation and stopped,while eliminating the phenomenon of machine-inch movement and noise.
7.The outer casing of the equipment using stainless steel packaging,easy cleaning and maintenance,in line national health standards.
Main technical parameters:
| Machine Model | KC-360N-A |
| production capacity | 300-360pcs/min |
| Total power | 1.5KW |
| Machine Dimension | (L*W*H)3.3*0.8*1.8m |
| Machine Weight | 600kgs |
Band-aid specifications can be made by KC-360N-A
| band-aid specifications | pcs/min |
| 56*18mm | 300-360 |
| 60*18mm | 300-360 |
| 60*19mm | 300-360 |
| 65*18mm | 300-360 |
| 65*19mm | 300-360 |
| 70*18mm | 300-360 |
| 72*19mm | 300-360 |
| 72*25mm | 280-340 |
| 76*19mm | 300-360 |
| 76*25mm | 280-340 |
| Diameter is 22mm | 220-300 |
