Name: 12v /24v 5a 10a solar street light controller with dc port
1. Microcomputer chip ensures accurate control
2. Perfect protections: over charge, over-discharge, reverse connection, PV cell panel reverse connection protection
3. Automatic brake and manual brake ensures th 12 volt 20 amp solar charge controller with led light at the wind turbine and the PV & wind hybrid charging controller operate safely and reliably
4. Voltage for automatic brake (rectified voltage of solar panel) and the recovery time after automatic brake can be adjusted in accordance with customer’s demands
5. High efficiency, soft braking, independent input circuits for wind turbine and the PV. As a result, if there is something wrong with one circuit, the other circuit can operate smoothly to provide stable power supply for load.
Specifications:
Model |
GT5 |
GT10 |
GT20 |
GT30 |
GT40 |
GT60 |
GT100 |
|
Rated Charge current(A) |
5 |
10 |
20 |
30 |
40 |
60 |
100 |
|
Rated DC voltage(V) |
12/24 |
12/24 |
12/24/ 48/96 (optional) |
12/24/ 48/96 (optional) |
48/96 (optional) |
48/96 (optional) |
48/96 (optional) |
|
Solar input |
Max voltage(V) |
42 |
42 |
21/42/ 84/168 |
21/42/ 84/168 |
84/168 |
84/168 |
84/168 |
Battery |
Over charge protective voltage(V) |
28.6 |
28.6 |
28.6/57.2/114 |
28.6/57.2/114 |
57.2/114 |
57.2/114 |
57.2/114 |
Over charge recover voltage(V) |
27.4 |
27.4 |
27.4/54.8 |
27.4/54.8 |
27.4/54.8 |
27.4/54.8 |
27.4/54.8 |
|
Constant charge voltage(V) |
27 |
27 |
27/54 |
27/54 |
54 |
54 |
54 |
|
Over discharge alarm voltage(V) |
20 |
20 |
20/40 |
20/40 |
40 |
40 |
40 |
|
Others |
Environment Humidity and temperature |
0-90% No condense,55°C |
||||||
Protective Functions |
Protection against anti-charge at night,battery over charge,over discharge protection,Joint-reversed of solar modules |
|||||||
Control method |
PWM |
|||||||
Size :D*W*H(mm) |
214*120*55 |
214*120*55 |
214*120*55 |
214*120*55 |
235*150*70 |
260*170*140 |
370*290*140 |
|
Package:D*W*H(mm) |
240*138*82 |
240*138*82 |
240*138*82 |
240*138*82 |
275*170*95 |
310*220*190 |
395*345*205 |
|
N.W/G.W(kg) |
0.6/0.8 |
0.6/0.8 |
0.6/0.8 |
0.6/0.8 |
1.3/1.5 |
2.5/2.9 |
5.4/6.6 |
|
Remark: if the hybrid system, the solar panel and wind turbine output need the same, then the system can work .such as if 1KW wind turbine output is 48V, solar panel output also need 48V.
Warranty:1 year
Delivery time:3-5 days for sample
