12/24v 20A pwm solar controller with USB
Features
1.Build-in industrial micro controller.
2.Big LCD display,all adjustable parameter.
3.Fully 4-stage PWM charge management.
4.Build-in short-circuit protection,open-circuit protection,reverse protection,over-load protection.
5.Dual MOS Reverse current protection ,low heat production.
Specifications
MODEL |
CY10A-1210 |
CY10A-1220 |
CY10A-1230 |
CY10A-4820 |
CY10A-4830 |
||
Batt voltage |
12V/24V auto |
48V |
|||||
Charge current |
10A |
20A |
30A |
20A |
30A |
||
Discharge current |
10A |
20A |
30A |
20A |
30A |
||
Max Solar input |
<50V |
<80V |
|||||
Equalization |
B01 sealed |
B02 Gel |
B03 flood |
||||
14.4V |
14.2V |
14.6V |
|||||
Float charge |
13.7V(defaul,adjustable) |
||||||
Discharge stop |
10.7V(defaul,adjustable) |
||||||
Discharge reconnect |
12.6V(defaul,adjustable) |
||||||
USB output |
5V/3A |
||||||
Self-consume |
<10mA |
||||||
Operating temperature |
-35~+60 ℃ |
||||||
Size/Weight |
150*78*35mm /150g |
||||||
*all red color voltage X2 ,X4 while using 24V /48V system.
*Product specifications are subject to change without prior notice.
