Help Center96 Cavity Preform Mold Supplier
Related Products
THE ADVANTANGE OF PET VAVLE TYPE PREFORM MOLD
1.cavaty,core and screw neck of steel adpot imported S136 in Sweden,and be heating treatment of hardness up to HRC 48- 50; All mold base do heat treatment of heardness up to HRC 30-35.
2.Advanced mould design technology:
Each cavity self-locks independently and using high precision JAPAN SYATEM.
To ensure low decent ration & precision of the product.
Each mold spare part be inserted with durable parts,which are interchangeable.
In order to improve and achieve high production efficiendy,we always design the best cooling system and can match a cooling machine for each mould.
3.Advanced & accurated vavle hot runner & tempertature controller,ensure reliability of production and high transperendy & brightness of product.
4.Mould sliding use copper,bottle be achieved FOOD SECURITY standard,and mold life guarantee more than 3 million shots.
CUSTOMER SUPPORT
Our PET group provides an experienced team ready to support you in inplementing your preform mould and hot runner concepts.Our service starts with individual assistance in the pre-sales stage and does not end with supplying the mould but instead continues through to the end of he mold lifetime.
COOLING SYSTEM
spiral water cooling way on cavity enhances mold cooling.
cooling system on neck and move neck plates brings an enhance cooling.
precise distributary plate distributes cooling water into cavity evenly,quicken preform cooling.
HOT RUNNER
hot runner balance design ensures evenly force,uniform heating and identical preform.
less energy cost and pressure lost.
independent cavity control system ensures nozzle temperature fluctuates within 1 .
Adopt imported heating devices,Germany Hotset or Italy Rotfil.
PREFORM MOLD STRUCTURE:
LONG-CUTTING GENERAL PREFORM MOLDS
LONG-CUTTING DOUBLE-LOCK PREFORM MOLDS
SHORT-CUTTING GENERAL PREFORM MOLDS
SHORT-CUTTING DOUBLE-LOCK PREFORM MOLDS
NO-CUTTING PIN-VAVLE PREFORM MOLDS
MOLD DATE
No,of cavity 12cavity 16cavity 24cavity 32cavity 48cavity 72cavity
18g(cm) 62*38*43 79*38*43 88*46*45 86*68*48 105*68*55 110*78*58
weight(kg) 630 810 1150 1750 2450 3100
28g(cm) 62*38*45 79*38*45 88*46*48 86*68*52 105*68*58 110*78*62
weight(kg) 660 850 1250 1900 2600 3350
40g(cm) 62*38*48 79*38*48 88*46*50 86*68*55 105*68*62 110*78*65
weight(kg) 690 890 1350 2000 2750 3500
.The thickness and weight of moulds are in accordance with the tubes,these measurements will change in case the products are improved.
