Home > Health & Medicine > Beauty Equipment > Skin Beauty Equipment > 10600nm (CE Approved)Fractional CO2 Laser Cutting Machine Face Lifting For Facial Treatment & Pregnancy Scar Removal(OD-C600)

10600nm (CE Approved)Fractional CO2 Laser Cutting Machine Face Lifting For Facial Treatment & Pregnancy Scar Removal(OD-C600)

10600nm (CE Approved)Fractional CO2 Laser Cutting Machine Face Lifting For Facial Treatment & Pregnancy Scar Removal(OD-C600) thumbnail-1
10600nm (CE Approved)Fractional CO2 Laser Cutting Machine Face Lifting For Facial Treatment & Pregnancy Scar Removal(OD-C600) photo-1
US$ 1 - 5,900 MOQ: 1 Piece
Key Specifications
Get Latest Price
Laser Type:
CO2 Laser
Q-Switch:
No
Style:
Stationary
Contact Supplier Request Quote Chat Now
Guangzhou ODI Science And Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Laser Type CO2 Laser
Q-Switch No
Style Stationary
Certification CE
Place of Origin Guangdong, China
Brand Name ODI
Model Number OD-C600
Feature Pigment Removal, Pore Remover, Skin Rejuvenation, Skin Tightening, Whitening, Other, Pigment Removal, Pore Remover, Skin Rejuvenation, Skin Tightening, Whitening, Scars removal


Principle:

  1. Fractional resurfacing is a new laser treatment modality that creates numerous microscopic thermal injury zones of controlled width, depth,and density that are surrounded by a reservoir of spared epidermal and dermal tissue,allowing for rapid repair of laser-induced thermal injury. This unique modality, if implemented with proper laser- delivery systems, enables high-energy treatments while minimizing risks.
    2.This machine use the RF Tube manufacturerd by Coherent America,the frequency can reach more than5000HZ,the high speed can work more efficiecnt and effectively,it is very good for the ultra pulse incision for the precise surgey,no blood,the treatment area is very clear,andless down time.

Specifications


2. CE approved
3.can be medical used
4. increasing cutting speed



(CE approved)Fractional CO2 laser cutting machine for facial treatment & pregnancy scar removal(OD-C600)



 Specifications

1. Mutifunctional beauty equipment
2. CE approved
3.can be medical used
4. increasing cutting speed

(CE approved)Fractional CO2 laser cutting machine for facial treatment & pregnancy scar removal(OD-C600)How does it work of fractional CO2 laser laser cutting mechine?



The Fractional CO2 Laser Beauty Equipment with a specific wavelength of 10.6 nm can be absorbed by human body tissue. Through fractional CO2 laser emitter, the micropulsed CO2 laser beam shoots on the target skin. Heat and electromagnetic effect of the fractional CO2 laser are adopted to conduct non-blood or less-blood cutting, cauterizing, gasification and minimally invasive treatment, which help avoid skin burnt. During the treatment, biochemical reactions of optical-thermal accelerate collagen reproduction and skin recovery. Fresh and smooth skin regenerate after exfoliation of tiny scar.

Applications:



Functions of fractional CO2 laser cutting machine


1. Remove all kinds of wrinkles(brow veins, glabella veins, neck veins, pregnancy veins and so on
2. Strengthen and tighten skin, lift up face
3. Skin rejuvenation
4. Age spots and blemishes, acne and speckle treatment, blain acne, scabby acne, allergic acne, papilla acne, improving the appearance of lipoidic skin and acne pit.
5. Treat telangiectasis
6. Recover skin damaged by sun and remove scars caused by acne, surgery etc.
7. Remove skin excrescence, such as wart etc.



Advantages of fractional CO2 laser cutting machine



1. Wide range application with this, effective treatment
2. Easy and fast treatment, no down time
3. Particular designed intelligent laser control system.





 Technical parameters of fractional CO2 laser cutting machine



























Technical Parameters

Features:

1. Reduced thermal damage to surrounding tissues

2. Rapid healing and minimal downtime

3. Stimulate deeper collagen with high pulse energy

4. LCD display panel provides easy operation with the latest microprocessor technology

5. Adjustable scanning patterns and size

6. Adjustable intensity of pilot beam from zero to maximum

7. Adjustable pulse duration

8. Last treatment setting memorization

9. Automatic alarm system for operation and troubles

10. Covers all functions of conventional system

11. No consumable costs


Fractional Co2 laser treatment:

Ultrapulse fractional co2 laser emits thousands of deep, tiny focal spot columns in your skin, called microscopic treatment zones. These lights penetrate into dermis skin, gasify the tissues around wrinkles and scars in an instant and make a signal of compounding collagen like tissues repair, collagen rearrangement ettc to regain a new fresh and healthy skin of youth.




  Basic info		 Laser tpe CO2 laser
Wavelength 10.6µ m, far-infrared laser
Pulsed radio frequency 0.530W
Ultra-pulse Power Average 5-30W
Display screen 8.4 inch LCD color touch screen



  Matrix mode		 Working state Normal Scan
Laser energy 1-30W, step value 1W 5-45mJ, step value 5mJ
Scan graphics square round eilipese rectangle line hexagon
Scan pattern size 0.1mm*0.1mm-20mm*20mm
Scan mode Sequence scan or randon scan
Dots quantity 400 dots at most
Pulse duration 0.1-10ms
Spot distance 0.1-2mm
Pulse energy 1mJ-100mJ is optional for each dot
Cooling system Wind and water circulation
Laser apparatus Sealed-off laser device stimulated by direct current


Specifications		 Condenser focus f=50mm
Beam divergence angle 0.3 mrad
Spot size ≥ 0.2mm at the focus
Radiation time/interval time 0.011s
Aiming beam < 2mW, 635nm red semiconductor laser
Power supply AC110V/220V, 50Hz/60Hz
Dimension 123cm*45cm*75cm
Weight 50kg
Application Scope *Beauty use: any pigmented nevus, spot, acne, syringoma, lipomyoma, hemangioma, scar, xanthelasma, lower blepharoplasty, tattoo, eyebrow excision assistance, wrinkle removalsurgery.


*Medical use: any pigmented nevus, spot, wart, nasal polyp, hypertrophy of turbinates, snoring, hemangioma, scar, skin tag, hemorrhopds and fistula, helosis, bromhidrosis, cervicitis, cervical erosion, vulva vitiligo, circumcision, tattoo, condyloma acuminatum, ect.

  Unique Advantages   Apply extensively to dermatology, gynecology, otorhinolaryngology, dentistry, general or beauty surgery for incision, vaporization, cauterization and solidification treatment.



Screen  of fractional CO2 laser cutting machine

(CE approved)Fractional CO2 laser cutting machine for facial treatment & pregnancy scar removal(OD-C600)

Detail picture of fractional CO2 laser cutting machine

 (CE approved)Fractional CO2 laser cutting machine for facial treatment & pregnancy scar removal(OD-C600)Detail



Pictures about us:

(CE approved)Fractional CO2 laser cutting machine for facial treatment & pregnancy scar removal(OD-C600)(CE approved)Fractional CO2 laser cutting machine for facial treatment & pregnancy scar removal(OD-C600)

(CE approved)Fractional CO2 laser cutting machine for facial treatment & pregnancy scar removal(OD-C600)



After sale service we provided



Provided

services
  1. One-year warranty for the mainframe without charges for components change or repairing. Lifetime maintenance without any charge for repair fee. Only fees to change parts.
  2. Free training for operation of the machine in our company, which provided by our specialized training department.
  3. On-line services, for example, technical consultancies provided by our skilled technique group concerning any question of the laser machine, and after-sale maintenance and more.
  4. OEM/ODM services are available. We have our own developing and design department and manufacturing line, which ensure your required beauty machine.

(CE approved)Fractional CO2 laser cutting machine for facial treatment & pregnancy scar removal(OD-C600)



Brief Introduction



Refine super pulsed CO2 laser Refine is a classic minimally invasive laser equipment for dermatologic surgery. This latest super pulsed laser emission system delivers hundreds of orderly micron pulsed laser beam on skin lesions, for controllable and accurate treatment by means of adjusting the size, density, distance,nature of the multiple arrays, and the diameter and the depth of the pore.



The treatment of Refine is very safe and can cover any part of the body. Its applications include a variety of wrinkles(forehead lines,eyebrow lines,eye wrinkles,perioral wrinkles,neck lines,stretch marks etc.),sagging skin, drooping eyelids, eyes bags, acne(whelk) marks, all kinds of scar(trauma scar,burn scar,suture scar),stains etc.


Product Tags: total fx laser , facial rejuvenation laser , fractional laser resurfacing acne scars
