CO2 Fractional Laser Equipment Skin Renewing F7 With Medical CE ISO13485 FDA Approved

CO2 Fractional Laser Equipment Skin Renewing F7 With Medical CE ISO13485 FDA Approved thumbnail-1
CO2 Fractional Laser Equipment Skin Renewing F7 With Medical CE ISO13485 FDA Approved photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Laser Type:
CO2 Laser
Q-Switch:
Yes
Style:
Stationary
Contact Supplier Request Quote Chat Now
Beijing Shijizhengfang Science And Technology Development Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Laser Type CO2 Laser
Q-Switch Yes
Style Stationary
Certification Medical CE and ISO13485
Place of Origin Beijing, China
Brand Name Anybeauty
Model Number F7

Application:



1. Application Range of Fractional treatment handpiece
    a. Large pores, Fine lines, Skin tightening and whitening, Skin loosen(Deep Wrinkles), Stretch marks.
    b. Various Scars: Burn Scars, Acne Scars, Surgical Scars and Keloid;
    c. Reconstruction of photoaging skin.

2. Application Range of Incision Handpiece
    a. Via multiple handles it can be adapted to Gynecology, ENT, Neurology and general surgery
    b. In cosmetic surgery, it can be adapted to incisions for Blephaplasty, Skin Tags and Ingrow Nails, Compound Nevus and Intra Dermal Nevus etc


Specifications


2)RF metal tube
3)7 output patterns
4)color touch screen

Fractional co2 Laser Machine F7:

Application
  1. Remove acne, acne scar, scar and so on.
  2. Dispel wrinkle around the eyes, crow's-feet, and wrinkle formed by lack of water.
  3. Effectively reduce the wrinkle on the face, forehead, the joints and striae gravidarum.
  4. Dispel freckle, nevus zygomaticus and other spots formed by hyperchromic pathological changes.
  5. Tighten skin and lift face.
  6. Remove striae gravidarum and other deep scars.

Principle

Ultrapulse treatment is a "fractional" treatment that produces thousands of deep, tiny columns

 in your skin, called microscopic treatment zones. FLT is "fractional" in that it intensively treats

old epidermal pigment cells without affecting any of the surrounding tissue, which reduces healing

 time (about 24 hours) and promotes the skin's natural process for creating new, healthier

tissue to replace the damaged cells. Ultra pulse treatment is a safe, non invasive procedure that allows you to rediscover the fresh, healthy skin of your youth.

Features
  1. Super large color touch LCD, more sensitive, more comfortable and accurate operating
  2. 6 joint arms, more convenient operating ,less costs
  3. Output patterns are more than 7.The requirements of different patients can be satisfied.
  4. Fractional and super-pulse can be switched at random. There is a wider use in clinical application.
  5. Focal spot diameter and interval are adjustable. Patient’s unique needs can be met during treatment.
  6. CPU imported from America can work stably and has excellent performance.
  7. There are 3 mode CPG, 10W, 20W, 30W, which can be installed according to different needs .

Technical Specification

Electrical Requirements

AC 220V±10% 50Hz

AC 110V±10% 60Hz

Beam Delivery

6 joint arm

Wavelength

10600nm

Cooling

Air cooling

Aiming wavelength

635nm

Output mode

Continuous, super pulse, fractional

Focal Spot Diameter

0.25mm

Operating mode

Continuous, operation with, intermittent loading

Power of Aiming Beam

≤5mw

Whether Preview or not

Yes

Pulse Interval

1ms-5000ms, every stepping 1ms

Times of scanning

1th-20th,every stepping 1th

Pulse Width

0.1ms-10ms ,every stepping 0.1ms

Scanning Mode

Disorder emitting, to one side as the base emitting in order, emitting by maximum distance

Output Power

1%-100%(adjustable), every stepping1%,10W,20W,30W(optional)

Output Pattern

Beeline, triangle, right square, rectangle, hexagon, rotundity, ellipse and so on

Spots Interval

0.1mm-2.6mm,every stepping 0.1mm

Pattern Size

Diagonal length from 0.1mm to 20mm is adjustable at random

Net Weight

45kg

Dimension

600mm×450mm×1080mm (L×W×H)

Technology of Ultrapulse
Mainly let the original average output of the laser energy concentrated in a very short period of time then output, due to the high pulse power, short time, and more round spot, the pressure on the surface from laser heat transfer effects is low (small heat-affected zone).

 CO2 Fractional laser equipment F7 with Medical CE, ISO13485

CO2 Fractional laser equipment F7 with Medical CE, ISO13485

 Theory - co2 fractional laser

CO2 laser system

The CO2 laser with a specific wavelength of 10.6 nm can be absorbed by human body tissue (no matter what color the skin is) by nearly 100%. Through laser emitter, the micropulsed laser beam shoots on the target skin in nanometer level to achieve a controllable precise treatment .The dimension of shooting area only can be measured in nanometer, which is precise enough for operators to control and adjust the treated depth andlayer according to the clinical diagnosis.

The energy of CO2 laser is even and steady. Its focused energy aims only at target tissue without any injury to surroundings. It is the heat and electromagnetic effect of the laser that people use to conduct non-blood or less-blood cutting, cauterizing, gasification and accurate microsurgery so as to avoid skin burnt. During the treatment, biochemical reactions of optical-thermal accelerate collagen reproduction and skin recovery,after exfoliation of the tiny scar; fresh and smooth skin can be regenerated. The device outputs invisible laser. In order to operate with more ease, red semiconductor laser has been added to indicate.


    CO2 Fractional laser is the most advanced conceptual fractional CO2 skin peeling laser system with a wavelength of 10600nm. In addition to its fine skin-peeling effect, it can effectively penetrate the laser beam into the dermis . It is the most beneficial skin recovery system and can achieve the long-term effect of collagen remodeling as well as improvement of aged skin conditions due to exposure to light. It can be very safely applied to various types of scars compared to the existing 100% total layer skin peeling lasers (CO2 or Er: YAG). In addition, it does not require a long period of recovery or side effects. It can remodel various types of deformed scars and skin tissue very effectively.
