Help CenterSkin Regeneration Doctor Use With Co2 Medical Treat Telangiectasis Laser Skin Rejuvenation/fractional Laser Co2 Cutting Machine
Related Products
-
Fractional Co2 Laser Scar and Pigment Removal Device/co2 Laser for Skin RejuvenationUS$ 6,000 - 12,500MOQ: 1 Piece -
CO2 Laser Vaginal Rejuvenation Treatment/CO2 Fractional Laser Vaginal TighteningUS$ 6,200 - 12,500MOQ: 1 Piece
-
Stretch Mark Removal Fractional Co2 Extraction Machine/fractional 8.0 Medical Carboxytherapy Inch Co2 Laser Vaginal Equipment Tattoo /lip Line Removal 10.6umUS$ 6,000 - 12,500MOQ: 1 Piece
-
2015 The Newest Technology Co2 Fractional Laser Machine With American Vagina Tightening RF Tube For Scar Removal And Wrinkle Removal Wrinkle RemovalUS$ 1 - 2MOQ: 1 Unit
-
2015 Newest Technology: Co2 Laser Glass Tube Cutting Machine/ Laser Facial Rejuvenation MachineUS$ 1 - 2MOQ: 1 Unit
Fractional Co2 laser treatment:
Ultrapulse fractional co2 laser emits thousands of deep, tiny focal spot columns in your skin, called microscopic treatment zones. These lights penetrate into dermis skin, gasify the tissues around wrinkles and scars in an instant and make a signal of compounding collagen like tissues repair, collagen rearrangement ettc to regain a new fresh and healthy skin of youth.
Doctor use with co2 medical laser skin rejuvenation/fractional laser co2 cutting machine
Our Product Advantage:
| 1. RF Laser Tube is more stable than traditional Glass tube, the machine is non serviceable |
2. With the RF laser Tube, the scanning depth can reach the derma layer ,to accelerate the collagen re-growth. |
| 3. RF Laser Tube makes the scanning dot much thinner and less harm |
|
4. The Laser Tube frequency can reach more than 5000HZ, high scanner can get better treatment effect |
5. Four working modes ,Fractional, CW, Pulse, Ultra Pulse ,one machine can been used in widely in different surgery |
6. Special designed energy self-inspected and energy-replenishment system, improving the stability and effect |
| 7. Multi safety protection, water, electric ,remote interlock warning alarm |
| 8. Laser anti-leak designing, confirm the operator and client safety |
| 9. Whole low voltage system, no electric danger and no electric radiation |
The Machine Detailed Application:
| Cosmetic Application | Rhytides (Wrinkles) | Medical Application | Actinic keratosis (sun-damaged skin, precancerous lesions) |
| Mottled dyspigmentation | Seborrheic keratosis (sun-damaged skin, precancerous lesions) | ||
| Telangiectasia (Red Spots) |
Sebaceous hyperplasia (yellow, shiny bumps on the face) |
||
| Solar lentignes (Brown spots) |
Rhinophyma (nose swelling and tissue over growth |
||
| Large pores,Rough skin texture | Epidermal Melasma (Brown spots) |
The All Detailed Specification:
| Laser source | RF Laser Tube |
| (Manufactured by Coherent America) | |
| Working Mode | Fractional Mode |
| Continuous Wave Mode (CW) | |
| Pulse Mode (single and repeated) | |
| Ultra Pulse Mode | |
| Laser Wavelength | 10600nm |
| Power of laser generator | Max 60W |
| Output Power | 1-30W |
| Focus Diameter | ≤0.1-1.2 mm |
| Treatment Depth | Max 2mm |
| Aiming Beam | Red Diode laser (650nm,≤5mW) |
| Delivery System | 7-Articulation Joint Spring Arm |
| Scanning Area | Max 20×20mm |
| Scanning shape | Ellipse, Rectangular, Triangular, Line, Square, Hexagon |
| Scanning mode | Sequence Mode |
| Middle split Mode | |
| Random Mode | |
| Smoke Exhausting System | Built-in air blow |
| Cooling system | Air Cooling |
| Environmental temperature | 5°C~40°C |
| Relative Humidity | ≤80% |
| Power Supply | ~220V±22V,50Hz±1Hz |
| Dimension | 450mm×550mm×1400mm |
| Weight |
40kg |
Parameters:
| Laser source | RF Laser Tube |
| (Manufactured by Coherent America) | |
| Working Mode | Fractional Mode |
| Continuous Wave Mode (CW) | |
| Pulse Mode (single and repeated) | |
| Ultra Pulse Mode | |
| Laser Wavelength | 10600nm |
| Power of laser generator | Max 60W |
| Output Power | 1-30W |
| Focus Diameter | ≤0.1-1.2 mm |
| Treatment Depth | Max 2mm |
| Aiming Beam | Red Diode laser (650nm,≤5mW) |
| Delivery System | 7-Articulation Joint Spring Arm |
| Scanning Area | Max 20×20mm |
| Scanning shape | Ellipse, Rectangular, Triangular, Line, Square, Hexagon |
| Scanning mode | Sequence Mode |
| Middle split Mode | |
| Random Mode | |
| Smoke Exhausting System | Built-in air blow |
| Cooling system | Air Cooling |
| Environmental temperature | 5°C~40°C |
| Relative Humidity | ≤80% |
| Power Supply | ~220V±22V,50Hz±1Hz |
| Dimension | 450mm×550mm×1400mm |
| Weight | 40kg |
Advantages of RF Co2 Fractional Laser:
| 1. RF Laser Tube is more stable than traditional Glass tube, the machine is non serviceable |
| 2. With the RF laser Tube, the scanning depth can reach the derma layer ,to accelerate the collagen re-growth. |
| 3. RF Laser Tube makes the scanning dot much thinner and less harm |
| 4. The Laser Tube frequency can reach more than 5000HZ, high scanner can get better treatment effect |
| 5. Four working modes ,Fractional, CW, Pulse, Ultra Pulse ,one machine can been used in widely in different surgery |
| 6. Special designed energy self-inspected and energy-replenishment system, improving the stability and effect |
| 7. Multi safety protection, water, electric ,remote interlock warning alarm |
| 8. Laser anti-leak designing, confirm the operator and client safety |
| 9. Whole low voltage system, no electric danger and no electric radiation |
Brief Introduction
Refine super pulsed CO2 laser Refine is a classic minimally invasive laser equipment for dermatologic surgery. This latest super pulsed laser emission system delivers hundreds of orderly micron pulsed laser beam on skin lesions, for controllable and accurate treatment by means of adjusting the size, density, distance,nature of the multiple arrays, and the diameter and the depth of the pore.
The treatment of Refine is very safe and can cover any part of the body. Its applications include a variety of wrinkles(forehead lines,eyebrow lines,eye wrinkles,perioral wrinkles,neck lines,stretch marks etc.),sagging skin, drooping eyelids, eyes bags, acne(whelk) marks, all kinds of scar(trauma scar,burn scar,suture scar),stains etc.
The Machine Parts Detailed Specification:
Before and After Treatment Effect Photos
Our Services:
1. Provide 2 year warranty
2. In two year, any problem, we will send spare parts to you by DHL. Provide video and file for your reference
3. Our Alibaba account online for 24 hours. Our phone is open for 24 hours.
4. Provide OEM and ODM service. Can design according to your demands
Our Factory Brief Details:
Our Factory Detailed Exhibition in World:
Principle:
Fractional resurfacing is a new laser treatment modality that creates numerous microscopic thermal injury zones of controlled width, depth,and density that are surrounded by a reservoir of spared epidermal and dermal tissue,allowing for rapid repair of laser-induced thermal injury. This unique modality, if implemented with proper laser- delivery systems, enables high-energy treatments while minimizing risks.
2.This machine use the RF Tube manufacturerd by Coherent America,the frequency can reach more than5000HZ,the high speed can work more efficiecnt and effectively,it is very good for the ultra pulse incision for the precise surgey,no blood,the treatment area is very clear,andless down time.
