Principle:
Fractional resurfacing is a new laser treatment modality that creates numerous microscopic thermal injury zones of controlled width, depth,and density that are surrounded by a reservoir of spared epidermal and dermal tissue,allowing for rapid repair of laser-induced thermal injury. This unique modality, if implemented with proper laser- delivery systems, enables high-energy treatments while minimizing risks.
2.This machine use the RF Tube manufacturerd by Coherent America,the frequency can reach more than5000HZ,the high speed can work more efficiecnt and effectively,it is very good for the ultra pulse incision for the precise surgey,no blood,the treatment area is very clear,andless down time.
10600nm Laser Beauty Equipment Fractional Laser Vaginal Tightening CO2 Extraction Machine
Working Theory of Co2 fractional machine
Co2 fractional resurfacing is a new laser treatment modality that creates numerous microscopic thermal injury
zones of controlled width, depth, and density that are surrounded by a reservoir of spared epidermal and dermal
tissue, allowing for rapid repair of laser-induced thermal injury. This unique modality, if implemented with proper laser-delivery systems, enables high-energy treatments while minimizing risks.
Detailed Application of fractional machine:
|
Cosmetic Application |
Rhytides (Wrinkles) |
Medical Application |
Actinic keratosis |
Mottled dyspigmentation |
Seborrheic keratosis |
||
Telangiectasia (Red Spots) |
Sebaceous hyperplasia |
||
Solar lentignes (Brown spots) |
Rhinophyma |
||
Large pores,Rough skin texture |
Epidermal Melasma |
Fractional Co2 laser treatment:
Ultrapulse fractional co2 laser emits thousands of deep, tiny focal spot columns in your skin, called microscopic treatment zones. These lights penetrate into dermis skin, gasify the tissues around wrinkles and scars in an instant and make a signal of compounding collagen like tissues repair, collagen rearrangement ettc to regain a new fresh and healthy skin of youth.
Advantage of Co2Co2
1. RF Laser Tube is more stable than traditional Glass tube, the machine is non serviceable.
2. RF Laser Tube makes the scanning dot much thinner and less harm.
3. The Laser Tube frequency can reach more than 5000HZ, high scanner can get better treatment effect.
4. Three working modes, CW, Pulse, Ultra Pulse ,one machine can been used in widely in different surgery.
5. Special designed energy self-inspected and energy-replenishment system ,improving the stability and effect.
6. Multi safety protection, water, electric ,remote interlock warning alarm.
7. Laser anti-leak designing, confirm the operator and client safety.
8. Whole low voltage system, no electric danger and no electric radiation
Specification of Co2:
|
Laser source |
RF Laser Tube (Manufactured by Coherent America) |
Working Mode |
Fractional Mode Continuous Wave Mode (CW) Pulse Mode (single and repeated) Ultra Pulse Mode |
Laser Wavelength |
10600nm |
Power of laser generator |
Max 60W |
Output Power |
1-30W |
Focus Diameter |
≤0.1-1.2 mm |
Treatment Depth |
Max 2mm |
Aiming Beam |
Red Diode laser (650nm,≤5mW) |
Delivery System |
7-Articulation Joint Spring Arm |
Scanning Area |
Max 20×20mm |
Scanning shape |
Ellipse, Rectangular, Triangular,Line ,Square, hexagon |
Scanning mode |
Sequence Mode Middle split Mode Random Mode |
Smoke Exhausting System |
Built-in air blow |
Cooling system |
Air Cooling |
|
Environmental temperature |
5°C~40°C |
Relative Humidity |
≤80% |
Power Supply |
~220V±22V,50Hz±1Hz |
Dimension |
1280x52x68mm |
Weight |
45kg |
The Machine Parts of Co2
9*9mm Gynecology Scanning Head
----For Vaginal Tightening, Vaginal wall thickening,treatment of urinary
Our services
1). 2 years warranty with lifetime free service and maintenance
2). Free training for operation of the equipment in our company, which provided by our specialized training
department.
3). On-line services, for example, technical consultancies provided by our skilled technique group concerning any
question of the laser equipment, and after-sale maintenance and more.
4). OEM/ODM services are available. We have our own developing and design department and manufacturing
line, which ensure your required beauty equipment
5). Professional after-sale service team, solve all the problems in time
Packing and Delivery
Package: customized poly + aluminium case
Delivery:3-5 working days after receiving the payment.
Payment: T/T, Western Union, Paypal . etc.
Features:
1. Reduced thermal damage to surrounding tissues
2. Rapid healing and minimal downtime
3. Stimulate deeper collagen with high pulse energy
4. LCD display panel provides easy operation with the latest microprocessor technology
5. Adjustable scanning patterns and size
6. Adjustable intensity of pilot beam from zero to maximum
7. Adjustable pulse duration
8. Last treatment setting memorization
9. Automatic alarm system for operation and troubles
10. Covers all functions of conventional system
11. No consumable costs
Our Factory Brief Details:
Our Factory Detailed Exhibition in World:
Brief Introduction
Refine super pulsed CO2 laser Refine is a classic minimally invasive laser equipment for dermatologic surgery. This latest super pulsed laser emission system delivers hundreds of orderly micron pulsed laser beam on skin lesions, for controllable and accurate treatment by means of adjusting the size, density, distance,nature of the multiple arrays, and the diameter and the depth of the pore.
The treatment of Refine is very safe and can cover any part of the body. Its applications include a variety of wrinkles(forehead lines,eyebrow lines,eye wrinkles,perioral wrinkles,neck lines,stretch marks etc.),sagging skin, drooping eyelids, eyes bags, acne(whelk) marks, all kinds of scar(trauma scar,burn scar,suture scar),stains etc.
