Our Services
1.We will guarantee the quality of our equipment, all the beauty machines will have over 48 hours test, then the QC department check again the stability before packing.
2.If there is a deficiency, please leave message or call us, our technical department will check the machinesituation face to face on internet or you take some videos to show the situation. We will give reply and solve method within 24 hours.
Introduction to the system
The Big Spot SHR&IPL Hair removal System can generate intense pulse light to take effect on the target issue for removal
of pigment, blood streaks, unexpected hairs and skin rejuvenating.
The system utilizes the selective absorption elements of the light.
The system consists of following major components:
Computer system,
System console
Operating interface
Treatment handle
The system console contains running module and computer system. The
embedded microprocessor monitors and controls the system continuously.
Operating Interface consists of 8.4 inch LCD screen, Key switch and emergency shut off knob.
The screen shows the system work program, treatment parameters and number of light emitting.
The treatment handle houses the mechanisms that generate the intense pulse light and the light
guide, designed for operating by hand.
Introduction to the operation
The main functions of the system are as followings
A. Pathology of Pigments
B. Pathology of Blood Vessels
C. Ageing of the skin
D. Black eye socket and other abnormal pigments.
1.2 System components description
Touch display screen:
Emergency shut-off knob:
Key switch:
Mainframe box:
integrated circuit etc.
Treatment handle:
1.3 System Interface
Technical parameter
Laser Type |
Intense Pulse light |
Wavelength |
560-1200 nm, 690-1200nm |
Output mode |
Pulsed |
Control mode |
Touch |
Transmission |
Crystal light system |
Safety class |
Class I type B |
Screen size |
8.0 inch |
Energy Density |
IPL mode:10-60J/cm2 (deviation≤±2%) |
|
SHR mode:1-15 J/cm2 |
|
SHR/SSR Light frequencfy |
1-10Hz Working Theory: Applying the technology of IPL and Bipolar Radio Frequency, the system acts on the entire corium layer, epidermal layer and subcutaneous tissue. On one hand, IPL destroys pathological pigments by photothermolysis effect, and stimulates the collagen and elastic fiber and gets the effect of tightening and whitening, on the other hand, biopolar RF release about 10 MHZ radio wave, high frequency vibration makes the skin molecule creating heat energy by friction, when the temperature reaches 68℃-72℃,the collagens extend will reproduce and recombine, enhance getting the effect of tightening skin and removing wrinkles. |
Pulse width |
1-10ms |
HR/SR continuous light interval |
1-3S, STE: 0.5S |
Spot size |
8*34mm(SSR/SR Slective) 16*57(SHR/HR Slective) ( deviation ≤0.2mm) |
Crystal temperature |
0-30℃ |
Cooling system |
Semi-conductor+water+Air |
Dimension |
58cm*28cm*36cm |
Net weight |
About 20kg |
Fuse |
Ø5×2020A |
Input power |
1200W |
Power supply |
AC220V±10%/50HZ |
Internal structure
Treatment Principle
Precipulse IPL Therapy System follows selective photothermolysis principle.Certain wavelength that can be used in and absorbed by targeted tissues.Targeted tissues will be destroyed according to targeted chromophore's selective absorption to light.What's more,the pulse width shall be smarller than or equal to targeted tissues' thermal relaxation time,then its damage to surrounding tissues will be minimized because of insufficient time for heat delivery.
1.6 Treatment handle
Our Service and Advantage:
1.The warranty time is 2 years.
2. All life the accessories is free,any time can delivery it for you timely and safely !
3.Once you are order the machine from us,we will free send you with the user manual and
CD guide for your learn and check.
4.We have operation vedio,if you are interesting it or want to learn more,please contact
us and enquire for us now,i will send you the all details for you soon,we are waiting for
you 24 hours online !
5.We are sincerely wanted the distributor from all over the world,if you are sell it good and
quantity are more,we will special give you the cost offer to support you and send our
engineer to customers door free training three days.
6.Our factory had in this line 10 years,we are rich experience in workmanship.Technology.
Delivery and After Sell Service,help customers clear custom,so we are acquire the
customers credit and approval in every apects,in addition,our product quality passed
thousand of customers test and ourselves modified many time,the machine is perfect and
superior,the treatment effect is good !!
Brief introduction about factory
Exhibition Photos:
IPL SHR Machine advantages:
1. The pulse energy keep stable, not fade away
2. Icons combined with letters on the screen, more easy for understanding and operating
3. Two fans equiped on the sides for better heat dissipation
4. Inner the back of machine, the lines are neat, the consumables keep on the outside, for easy replacement
