Specifications
1.Easy to install.2.Economical and energy saving.
3.Sanitary environment.
4.Reliable quality.
5.Professional services.
1.SW series standard tunnel type netting belt simple freezer date
|
Type |
kg/h Capacity |
kw Refrig Capacity |
kw Rated Power |
m Size |
SW100 |
100 |
15.0 |
2.25 |
6.6×1.8×2.1 |
SW150 |
150 |
21.5 |
2.95 |
8.0×1.8×2.2 |
SW250 |
250 |
40.0 |
4.95 |
10.8×1.8×2.5 |
SW300 |
300 |
42.0 |
6.50 |
9.5×2.25×2.5 |
SW500 |
500 |
71.0 |
10.3 |
12.2×3.0×2.5 |
SW1000 |
1000 |
142.0 |
19.8 |
18.5×3.0×2.5 |
SW1500 |
1500 |
213.0 |
28.6 |
22.1×3.5×2.5 |
SW2000 |
2000 |
284.0 |
39.6 |
20.3×5.1×2.5 |
Account by naked jelly dumpling, up anticipate the density 10kg/ , pass in and out goods temperature +15/-18 , the congelation temperature-35 ± 2 ;Consuming cold quantity to press is congealed|evaporate temperature ±40 account.
2.Screw simple freezer
|
Type |
kg/h Capacity |
kw Refrig Capacity |
kw Rated Power |
m Size |
SL500 |
500 |
71.0 |
10.3 |
5.4×3.6×2.5 |
SL1000 |
1000 |
142.0 |
16.2 |
5.4×3.6×3.3 |
SSL100 |
1000 |
142.0 |
20.6 |
7.2×5.4×2.5 |
SSL1500 |
1500 |
212.0 |
28.6 |
10.8×4.8×2.9 |
SSL2000 |
2000 |
283.0 |
39.6 |
11.7×6.3×3.3 |
SSL3000 |
3000 |
420.0 |
52.8 |
12.6×7.0×3.9 |
Account by naked jelly dumpling, up anticipate the density 10kg/ , pass in and out goods temperature +15/-18 , the congelation temperature-35 ± 2 ;Consuming cold quantity to press is congealed|evaporate temperature ±40 account.
3.Fluidization simple freezer
|
Type |
kg/h Capacity |
kw Refrig Capacity |
kw Rated Power |
m Size |
SLD500 |
500 |
90.0 |
19.5 |
7.0×3.0×2.5 |
SLD1000 |
1000 |
170.0 |
28.0 |
10.0×3.0×2.5 |
SLD1500 |
1500 |
255.0 |
33.0 |
15.0×3.0×2.5 |
SLD2000 |
2000 |
320.0 |
41.0 |
16.0×3.3×2.5 |
SLD3000 |
3000 |
420.0 |
48.0 |
20.0×3.3×2.5 |
4.FSK Frigeast standard freezer series.
|
Type |
m |
Kg/h |
|
kW |
W |
|
FSK50 |
2.7×1.8×2.95 |
50 |
+15/-18 |
13.9 |
8263 |
R22/404A |
FSK100 |
2.7×1.8×2.95 |
100 |
+15/-18 |
17.5 |
13335 |
R22/404A |
FSK150 |
4×2.25×2.95 |
150 |
+15/-18 |
21.5 |
16532 |
R22/404A |
FSK200 |
4×2.25×2.95 |
200 |
+15/-18 |
25.75 |
26860 |
R22/404A |
FSK250 |
4×2.7×2.95 |
250 |
+15/-18 |
42 |
33064 |
R22/404A |
FSK400 |
4×2.7×2.95 |
400 |
+15/-18 |
51 |
53720 |
R22/404A |
Account by naked jelly dumpling,pass in and out goods temperature +15/-18
