Widely Used Concrete Mixer

Widely Used Concrete Mixer thumbnail-1
Widely Used Concrete Mixer thumbnail-2
Widely Used Concrete Mixer photo-1
Widely Used Concrete Mixer photo-2
US$ 9,991 - 49,978 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Power Type:
Electric
Place of Origin:
Henan, China
Contact Supplier Request Quote Chat Now
Henan Province Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Power Type Electric
Place of Origin Henan, China
Brand Name YU JIE
Model Number HZS50
Power(W) 85Kw
Dimension(L*W*H) 33.8*14.8m*10.8m
Weight 40T
Certification CE, ISO, Bv
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

widely used concrete mixerQuick Details

  • Condition: New
  • Power Type: Electric
  • Place of Origin: Henan, China (Mainland)
  • Brand Name: YU JIE
  • Model Number: HZS50
  • Power(W): 85Kw
  • Dimension(L*W*H): 33.8*14.8m*10.8m
  • Weight: 40T
  • Certification: CE, ISO, BV< SGS
  • Warranty: 15 months
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Model: HZS50
  • Rated Productivity: 50m3/h
  • Main Mixer: JS1000
  • Max. Aggregate Diameter: 80mm
  • Capacity of Aggregate Bin: 3*8.3m3
  • Capacity of Mixing Hopper: 1.6m3
  • Aggregate Conveying Mode: Lift Hopper
  • Control Mode: Centralized control manual operation
  • General Power: 85Kw
  • Discharging Height: 3.8 m

  • Model

    HZS50

    Rated Productivity

    50m3/h

    Main Mixer

    JS1000

    Max. Aggregate Diameter

    80mm

    Capacity of Aggregate Bin

    3*8.3m3

    Capacity of Mixing Hopper

    1.6m3

    Aggregate Conveying Mode

    Lift Hopper

    Aggregate Weighing Precision

    3000Kg ±2%

    Cement Weighing Precision

    900Kg ±1%

    Fly Ash Weighing Precision

    600Kg ±1%

    Water Weighing Precision

    600Kg ±1%

    Additive Weighing Precision

    100Kg ±1%

    General Power

    85Kw

    Total Weight

    40T

    Outline dimension (L*W*H)

    33.8*14.8m*10.8m

    Discharging Height

    3.8 m

    Control Mode

    Centralized control manual operation

    Powder Silos (Optional Parts)

    100T*2

    Screw Conveyors (

    Optional Parts)

    φ273mm*2

     widely used concrete mixerwidely used concrete mixer
