Single Shaft Cement Mixer

Single Shaft Cement Mixer thumbnail-1
Single Shaft Cement Mixer thumbnail-2
Single Shaft Cement Mixer photo-1
Single Shaft Cement Mixer photo-2
US$ 9,992 - 49,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
YU JIE
Contact Supplier Request Quote Chat Now
Henan Province Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Henan, China
Brand Name YU JIE
Model Number HZS35
Motor Power 60KW
Mixing Power 60KW
Charging Capacity 900L
Reclaiming capacity 750L
Speed of Mixing Drum 20r /minute
Water Supply Mode water pump
Working Cycle Period 60s
Discharge Way electrically hydraulic control
Outline Dimension 19.8m*8.2m*8.5m
After-sales Service Provided Engineers available to service machinery overseas

Quick Details

  • Condition: New
  • Power Type: Electric
  • Place of Origin: Henan, China (Mainland)
  • Brand Name: YU JIE
  • Model Number: HZS35
  • Power(W): 60KW
  • Dimension(L*W*H): 19.8m*8.2m*8.5m
  • Weight: 15000Kg
  • Certification: ISO9001:2001/CE
  • Warranty: 15 months after delivery from factory
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Model: HZS35
  • Theoretical productivity: 35m3/h
  • Concrete mixer: twin shafts forced JS750
  • Mixing Power: 30kw
  • Discharging capacity(L) of mixer: 750L
  • Aggregate size(Pebble/Macadam)(mm):80/60
  • Aggregate Bin volume(m3): 7m3*3
  • Belt conveying Capacity(t/h): 450
  • Total power(KW): 60Kw
  • Discharging height(M): 3.8 m
  •



    Model

    HZS35

    Rated Productivity

    35m3/h

    Main Mixer

    JS750 (0.75m3)

    Power of Main Mixer

    30KW

    Max. Aggregate Diameter

    80mm

    Feeding Mode

    Lift Hopper

    Aggregate Batching Machine

    PLD1200-III

    Storage Hopper

    7.3m3 x 3

    Aggregate Weighing Accuracy

    2200Kg ±2%c

    Cement Weighing Accuracy

    450Kg ±1%

    Water Weighing Accuracy

    (by flow meter)

    200Kg ±1%

    Additive Weighing Accuracy

    30Kg ±1%

    Discharging Height

    3.8 m

    Outline Dimension

    (L* W*H)

    19.8m×8.2m×8.5m

    General Power

    60KW

    Power Supply

    220V/380V, 50HZ

    Total Weight

    15000Kg

    Control Mode

    Semi-automatic batching, manual operation

    Cement Silos (Optional)

    50T or 100T as per customer’s requirement

    Screw Conveyor (Optional)

    φ219mm*8M*11kw

     single shaft cement mixersingle shaft cement mixersingle shaft cement mixer
