Compact Fishmeal Plant
This the the whole processing line of fishmeal.
The production process of fishmeal is as below:
Cooking-Pressing-Decanting-Drying-Cooling-Grindering and Packing
The fish passes through a electrical magnet to remove iron like fish hooks.
The raw material is cooked in a steam cooker where the protein of the mass is coagulated, the fish oil is liberated.
The mass from the cooker goes to twim screw press to squeeze out as much liquid as possible from the solid phase.
After pressing, we get press cake and press liquor.
The sludge is recovered in a decanter and then dryed in dryer after mixed with press cake.
The liquid after decanter is treated in a oil separator. In the high speed centrifuge, fish oil is separated. the stickwater goes to evaporator.
The stickwater is concentrated continously by the waste vapor from the dryer and cooker.
The press cake, sludge and stickwater concentrate is mixed together and is dryed in the disc dryer.
After drying process, the fish meal have to be cooled to room temperature by a cooler.
Usually the fish meal shall be grindered to fine particles before packing. After grinding, the fish meal shall be transported by an air-cooling screw conveyor before it is packed in a packing tank.
One small capacity data
1,fresh fish as the raw material,capacity1000kg/day 8 hours,final capacity is 300 kg per day,water content≤12% final meal is Skimmed(we have smaler,medium,big capacity,welcome inquire for the details)
2, flow chart
fresh fish,,cooking, pressing,,dry,,skimmed final fish meal
heating way,electriclty with heat oil 180°C power,24kw
3,Equipment Specifications
1,converyer,160×4000,1.1kw
2,electricity heating cooking pressing
275×3500 ,2.2kw
3,dryer machine,
600×3500 Configuration mixing within the tooth
4kw
Total power:31.3 Kw
4,Matched Equipment
The factory matched the power,valve, Instrumentation,heating pipe,tempreture controller, Starter, Heat carrier oil 320, High oil storage tank, Low oil storage tank
there are different capacity ,welcome inquire for the details!
Compact Fishmeal Plant Pet Food Processing Machines raw material fresh fish
fish processing plant Pet Food Processing Machines final meal skimmed fish meal or as your inquire
