High Speed Old Clothes Shredding Machine
1.Machine introduction:
1) New rack structure is scientific, reasonable and safe, the performance is reliable; operation is
stable, and easy to handle.
2) Output is high, good loosing and cleaning effects, low-loss, environmental and low noisy.
3 )Adopt to oblique gear speed reducer make the good adaptability during the long time working,
and will not be heat, has long life time.
4 )Equipped with the new designed rack, loosing and recycling combined working models, gradually
processing materials, reduce the damage to fiber, improve the length of fiber.
5) Special structure roller and arc-shaped cotton feeding board, and has long life time
6 )Gap is easy to adjust and maintenance
7 )Have thickened roller, four roller cotton feeding device, gear roller and other feeding type, is freeto choose according to different materials
2.Technical parameters:
Model |
HTO-SBJ500A |
HTO-SBJ500B |
HTO-SBJ800C |
HTO-SBJ800D |
HTO-SBJ1200A |
HTO-SBJ1200B |
Power |
3kw |
3kw |
5.5kw |
7.0kw |
9kw |
13.2kw |
Dimension |
1.8*1*1.1m |
2.8*1*1.1m |
3.2*1*1.1m |
6*1*1.1m |
6*1.4*1.2m |
6*1.4*1.2m |
Capacity |
300kg/h |
300kg/h |
800kg/h |
800kg/h |
1000-1500kg/h |
1000-1500kg/h |
Cutting times |
288/min |
288/min |
432/min |
1036/min |
777/min |
1036/min |
Conveyor |
1000*350mm |
1000*350mm |
1400*350mm |
2800*350mm |
2800*700mm |
2800*700mm |
Output conveyor |
NO |
1400*350mm |
1400*350mm |
2800*350mm |
2800*700mm |
2800*700mm |
Cutting thicknes |
20mm |
20mm |
30-50mm |
30-50mm |
30-60mm |
30-60mm |
3.Contact information
If you need further information, please contact us freely, we will do our best to cooperate with you.
