99.9% Recycling Rate Small Copper Cable Granulator
1.Machine introduction of Small Copper Cable Granulator:
HTO-400-1 adopts advanced design, rational structure, limited space and reliable operation. This machine includes crusher, vibrating screen, 3 blowers, one set of gatherer and electrical control system. The mixture will directly fall into vibrating screen after be crushed, and will go through separating blower, gathering blower and accessorial blower. With screen box straight shock excitation, the sheath and core will separate, and get copper particles, plastic pellets and mixture from different ports. Dust goes to dust gatherer through air flue. The vibrating screen and separating blower will be controlled by transducer, which can adjust frequency and the air value according to different conditions. This type of machine is easy to operation and maintenance, and the separated precision can reach 99.9%. It will be good choice for the common recycled factory which suitable crushing the wasted cable’s overall size below 20mm and single wire is 0.2-2mm, the capacity is 80~100kg/h.
2.Technical parameters of Small Copper Cable Granulator:
|
Model Item |
HTO-ZLJ400 |
Power/voltage |
19.51KW/380V |
Capacity |
80-100kg/h |
Dimension |
L1830×W1750×H2000mm |
Weight |
1388kg |
3.Contact information of Small Copper Cable Granulator:
3.Contact information
If you need further information, please contact us freely, we will do our best to cooperate with you.
